#include <windows.h>
 #include <windowsx.h>
 #include <tchar.h>
+#include <GL/gl.h>
+#include <fstream>
+
+#include "math.h"
+
+using namespace std;
+
+/////////////
+// DEFINES //
+/////////////
+#define WGL_DRAW_TO_WINDOW_ARB         0x2001
+#define WGL_ACCELERATION_ARB           0x2003
+#define WGL_SWAP_METHOD_ARB            0x2007
+#define WGL_SUPPORT_OPENGL_ARB         0x2010
+#define WGL_DOUBLE_BUFFER_ARB          0x2011
+#define WGL_PIXEL_TYPE_ARB             0x2013
+#define WGL_COLOR_BITS_ARB             0x2014
+#define WGL_DEPTH_BITS_ARB             0x2022
+#define WGL_STENCIL_BITS_ARB           0x2023
+#define WGL_FULL_ACCELERATION_ARB      0x2027
+#define WGL_SWAP_EXCHANGE_ARB          0x2028
+#define WGL_TYPE_RGBA_ARB              0x202B
+#define WGL_CONTEXT_MAJOR_VERSION_ARB  0x2091
+#define WGL_CONTEXT_MINOR_VERSION_ARB  0x2092
+#define GL_ARRAY_BUFFER                   0x8892
+#define GL_STATIC_DRAW                    0x88E4
+#define GL_FRAGMENT_SHADER                0x8B30
+#define GL_VERTEX_SHADER                  0x8B31
+#define GL_COMPILE_STATUS                 0x8B81
+#define GL_LINK_STATUS                    0x8B82
+#define GL_INFO_LOG_LENGTH                0x8B84
+#define GL_TEXTURE0                       0x84C0
+#define GL_BGRA                           0x80E1
+#define GL_ELEMENT_ARRAY_BUFFER           0x8893
+
+//////////////
+// TYPEDEFS //
+//////////////
+typedef BOOL (WINAPI   * PFNWGLCHOOSEPIXELFORMATARBPROC) (HDC hdc, const int *piAttribIList, const FLOAT *pfAttribFList, UINT nMaxFormats, int *piFormats, UINT *nNumFormats);
+typedef HGLRC (WINAPI  * PFNWGLCREATECONTEXTATTRIBSARBPROC) (HDC hDC, HGLRC hShareContext, const int *attribList);
+typedef BOOL (WINAPI   * PFNWGLSWAPINTERVALEXTPROC) (int interval);
+typedef void (APIENTRY * PFNGLATTACHSHADERPROC) (GLuint program, GLuint shader);
+typedef void (APIENTRY * PFNGLBINDBUFFERPROC) (GLenum target, GLuint buffer);
+typedef void (APIENTRY * PFNGLBINDVERTEXARRAYPROC) (GLuint array);
+typedef void (APIENTRY * PFNGLBUFFERDATAPROC) (GLenum target, ptrdiff_t size, const GLvoid *data, GLenum usage);
+typedef void (APIENTRY * PFNGLCOMPILESHADERPROC) (GLuint shader);
+typedef GLuint(APIENTRY * PFNGLCREATEPROGRAMPROC) (void);
+typedef GLuint(APIENTRY * PFNGLCREATESHADERPROC) (GLenum type);
+typedef void (APIENTRY * PFNGLDELETEBUFFERSPROC) (GLsizei n, const GLuint *buffers);
+typedef void (APIENTRY * PFNGLDELETEPROGRAMPROC) (GLuint program);
+typedef void (APIENTRY * PFNGLDELETESHADERPROC) (GLuint shader);
+typedef void (APIENTRY * PFNGLDELETEVERTEXARRAYSPROC) (GLsizei n, const GLuint *arrays);
+typedef void (APIENTRY * PFNGLDETACHSHADERPROC) (GLuint program, GLuint shader);
+typedef void (APIENTRY * PFNGLENABLEVERTEXATTRIBARRAYPROC) (GLuint index);
+typedef void (APIENTRY * PFNGLGENBUFFERSPROC) (GLsizei n, GLuint *buffers);
+typedef void (APIENTRY * PFNGLGENVERTEXARRAYSPROC) (GLsizei n, GLuint *arrays);
+typedef GLint(APIENTRY * PFNGLGETATTRIBLOCATIONPROC) (GLuint program, const char *name);
+typedef void (APIENTRY * PFNGLGETPROGRAMINFOLOGPROC) (GLuint program, GLsizei bufSize, GLsizei *length, char *infoLog);+typedef void (APIENTRY * PFNGLGETPROGRAMIVPROC) (GLuint program, GLenum pname, GLint *params);
+typedef void (APIENTRY * PFNGLGETSHADERINFOLOGPROC) (GLuint shader, GLsizei bufSize, GLsizei *length, char *infoLog);
+typedef void (APIENTRY * PFNGLGETSHADERIVPROC) (GLuint shader, GLenum pname, GLint *params);
+typedef void (APIENTRY * PFNGLLINKPROGRAMPROC) (GLuint program);
+typedef void (APIENTRY * PFNGLSHADERSOURCEPROC) (GLuint shader, GLsizei count, const char* *string, const GLint *length);
+typedef void (APIENTRY * PFNGLUSEPROGRAMPROC) (GLuint program);
+typedef void (APIENTRY * PFNGLVERTEXATTRIBPOINTERPROC) (GLuint index, GLint size, GLenum type, GLboolean normalized, GLsizei stride, const GLvoid *pointer);
+typedef void (APIENTRY * PFNGLBINDATTRIBLOCATIONPROC) (GLuint program, GLuint index, const char *name);
+typedef GLint(APIENTRY * PFNGLGETUNIFORMLOCATIONPROC) (GLuint program, const char *name);
+typedef void (APIENTRY * PFNGLUNIFORMMATRIX4FVPROC) (GLint location, GLsizei count, GLboolean transpose, const GLfloat *value);
+typedef void (APIENTRY * PFNGLACTIVETEXTUREPROC) (GLenum texture);
+typedef void (APIENTRY * PFNGLUNIFORM1IPROC) (GLint location, GLint v0);
+typedef void (APIENTRY * PFNGLGENERATEMIPMAPPROC) (GLenum target);
+typedef void (APIENTRY * PFNGLDISABLEVERTEXATTRIBARRAYPROC) (GLuint index);
+typedef void (APIENTRY * PFNGLUNIFORM3FVPROC) (GLint location, GLsizei count, const GLfloat *value);
+typedef void (APIENTRY * PFNGLUNIFORM4FVPROC) (GLint location, GLsizei count, const GLfloat *value);
+
+PFNGLATTACHSHADERPROC glAttachShader;
+PFNGLBINDBUFFERPROC glBindBuffer;
+PFNGLBINDVERTEXARRAYPROC glBindVertexArray;
+PFNGLBUFFERDATAPROC glBufferData;
+PFNGLCOMPILESHADERPROC glCompileShader;
+PFNGLCREATEPROGRAMPROC glCreateProgram;
+PFNGLCREATESHADERPROC glCreateShader;
+PFNGLDELETEBUFFERSPROC glDeleteBuffers;
+PFNGLDELETEPROGRAMPROC glDeleteProgram;
+PFNGLDELETESHADERPROC glDeleteShader;
+PFNGLDELETEVERTEXARRAYSPROC glDeleteVertexArrays;
+PFNGLDETACHSHADERPROC glDetachShader;
+PFNGLENABLEVERTEXATTRIBARRAYPROC glEnableVertexAttribArray;
+PFNGLGENBUFFERSPROC glGenBuffers;
+PFNGLGENVERTEXARRAYSPROC glGenVertexArrays;
+PFNGLGETATTRIBLOCATIONPROC glGetAttribLocation;
+PFNGLGETPROGRAMINFOLOGPROC glGetProgramInfoLog;
+PFNGLGETPROGRAMIVPROC glGetProgramiv;
+PFNGLGETSHADERINFOLOGPROC glGetShaderInfoLog;
+PFNGLGETSHADERIVPROC glGetShaderiv;
+PFNGLLINKPROGRAMPROC glLinkProgram;
+PFNGLSHADERSOURCEPROC glShaderSource;
+PFNGLUSEPROGRAMPROC glUseProgram;
+PFNGLVERTEXATTRIBPOINTERPROC glVertexAttribPointer;
+PFNGLBINDATTRIBLOCATIONPROC glBindAttribLocation;
+PFNGLGETUNIFORMLOCATIONPROC glGetUniformLocation;
+PFNGLUNIFORMMATRIX4FVPROC glUniformMatrix4fv;
+PFNGLACTIVETEXTUREPROC glActiveTexture;
+PFNGLUNIFORM1IPROC glUniform1i;
+PFNGLGENERATEMIPMAPPROC glGenerateMipmap;
+PFNGLDISABLEVERTEXATTRIBARRAYPROC glDisableVertexAttribArray;
+PFNGLUNIFORM3FVPROC glUniform3fv;
+PFNGLUNIFORM4FVPROC glUniform4fv;
+
+PFNWGLCHOOSEPIXELFORMATARBPROC wglChoosePixelFormatARB;
+PFNWGLCREATECONTEXTATTRIBSARBPROC wglCreateContextAttribsARB;
+PFNWGLSWAPINTERVALEXTPROC wglSwapIntervalEXT;
+
+typedef struct VertexType
+{
+       VectorType position;
+       VectorType color;
+} VertexType;
+
+HDC     g_deviceContext = 0;
+HGLRC   g_renderingContext = 0;
+char    g_videoCardDescription[128];
+
+const bool VSYNC_ENABLED = true;
+const float SCREEN_DEPTH = 1000.0f;
+const float SCREEN_NEAR = 0.1f;
+
+int     g_vertexCount, g_indexCount;
+unsigned int g_vertexArrayId, g_vertexBufferId, g_indexBufferId;
+
+unsigned int g_vertexShader;
+unsigned int g_fragmentShader;
+unsigned int g_shaderProgram;
+
+const char VS_SHADER_SOURCE_FILE[] = "color.vs";
+const char PS_SHADER_SOURCE_FILE[] = "color.ps";
+
+float g_positionX = 0, g_positionY = 0, g_positionZ = -10;
+float g_rotationX = 0, g_rotationY = 0, g_rotationZ = 0;
+float g_worldMatrix[16];
+float g_viewMatrix[16];
+float g_projectionMatrix[16];
+
+bool InitializeOpenGL(HWND hwnd, int screenWidth, int screenHeight, float screenDepth, float screenNear, bool vsync)
+{
+        int attributeListInt[19];
+        int pixelFormat[1];
+        unsigned int formatCount;
+        int result;
+        PIXELFORMATDESCRIPTOR pixelFormatDescriptor;
+        int attributeList[5];
+        float fieldOfView, screenAspect;
+        char *vendorString, *rendererString;
+
+
+        // Get the device context for this window.
+        g_deviceContext = GetDC(hwnd);
+        if(!g_deviceContext)
+        {
+                return false;
+        }
+
+        // Support for OpenGL rendering.
+        attributeListInt[0] = WGL_SUPPORT_OPENGL_ARB;
+        attributeListInt[1] = TRUE;
+
+        // Support for rendering to a window.
+        attributeListInt[2] = WGL_DRAW_TO_WINDOW_ARB;
+        attributeListInt[3] = TRUE;
+
+        // Support for hardware acceleration.
+        attributeListInt[4] = WGL_ACCELERATION_ARB;
+        attributeListInt[5] = WGL_FULL_ACCELERATION_ARB;
+
+        // Support for 24bit color.
+        attributeListInt[6] = WGL_COLOR_BITS_ARB;
+        attributeListInt[7] = 24;
+
+        // Support for 24 bit depth buffer.
+        attributeListInt[8] = WGL_DEPTH_BITS_ARB;
+        attributeListInt[9] = 24;
+
+        // Support for double buffer.
+        attributeListInt[10] = WGL_DOUBLE_BUFFER_ARB;
+        attributeListInt[11] = TRUE;
+
+        // Support for swapping front and back buffer.
+        attributeListInt[12] = WGL_SWAP_METHOD_ARB;
+        attributeListInt[13] = WGL_SWAP_EXCHANGE_ARB;
+
+        // Support for the RGBA pixel type.
+        attributeListInt[14] = WGL_PIXEL_TYPE_ARB;
+        attributeListInt[15] = WGL_TYPE_RGBA_ARB;
+
+        // Support for a 8 bit stencil buffer.
+        attributeListInt[16] = WGL_STENCIL_BITS_ARB;
+        attributeListInt[17] = 8;
+
+        // Null terminate the attribute list.
+        attributeListInt[18] = 0;
+
+
+        // Query for a pixel format that fits the attributes we want.
+        result = wglChoosePixelFormatARB(g_deviceContext, attributeListInt, NULL, 1, pixelFormat, &formatCount);
+        if(result != 1)
+        {
+                return false;
+        }
+
+        // If the video card/display can handle our desired pixel format then we set it as the current one.
+        result = SetPixelFormat(g_deviceContext, pixelFormat[0], &pixelFormatDescriptor);
+        if(result != 1)
+        {
+                return false;
+        }
+
+        // Set the 4.0 version of OpenGL in the attribute list.
+        attributeList[0] = WGL_CONTEXT_MAJOR_VERSION_ARB;
+        attributeList[1] = 4;
+        attributeList[2] = WGL_CONTEXT_MINOR_VERSION_ARB;
+        attributeList[3] = 0;
+
+        // Null terminate the attribute list.
+        attributeList[4] = 0;
+
+        // Create a OpenGL 4.0 rendering context.
+        g_renderingContext = wglCreateContextAttribsARB(g_deviceContext, 0, attributeList);
+        if(g_renderingContext == NULL)
+        {
+                return false;
+        }
+
+        // Set the rendering context to active.
+        result = wglMakeCurrent(g_deviceContext, g_renderingContext);
+        if(result != 1)
+        {
+                return false;
+        }
+
+        // Set the depth buffer to be entirely cleared to 1.0 values.
+        glClearDepth(1.0f);
+
+        // Enable depth testing.
+        glEnable(GL_DEPTH_TEST);
+
+        // Set the polygon winding to front facing for the left handed system.
+        glFrontFace(GL_CW);
+
+        // Enable back face culling.
+        glEnable(GL_CULL_FACE);
+        glCullFace(GL_BACK);
+
+               // Initialize the world/model matrix to the identity matrix.
+               BuildIdentityMatrix(g_worldMatrix);
+
+               // Set the field of view and screen aspect ratio.
+               fieldOfView = PI / 4.0f;
+               screenAspect = (float)screenWidth / (float)screenHeight;
+
+               // Build the perspective projection matrix.
+               BuildPerspectiveFovLHMatrix(g_projectionMatrix, fieldOfView, screenAspect, screenNear, screenDepth);
+
+        // Get the name of the video card.
+        vendorString = (char*)glGetString(GL_VENDOR);
+        rendererString = (char*)glGetString(GL_RENDERER);
+        // Store the video card name in a class member variable so it can be retrieved later.
+        strcpy_s(g_videoCardDescription, vendorString);
+        strcat_s(g_videoCardDescription, " - ");
+        strcat_s(g_videoCardDescription, rendererString);
+
+        // Turn on or off the vertical sync depending on the input bool value.
+        if(vsync)
+        {
+                result = wglSwapIntervalEXT(1);
+        }
+        else
+        {
+                result = wglSwapIntervalEXT(0);
+        }
+
+        // Check if vsync was set correctly.
+        if(result != 1)
+        {
+                return false;
+        }
+
+        return true;
+}
+
+bool LoadExtensionList()
+{
+        // Load the OpenGL extensions that this application will be using.
+        wglChoosePixelFormatARB = (PFNWGLCHOOSEPIXELFORMATARBPROC)wglGetProcAddress("wglChoosePixelFormatARB");
+        if(!wglChoosePixelFormatARB)
+        {
+                return false;
+        }
+
+        wglCreateContextAttribsARB = (PFNWGLCREATECONTEXTATTRIBSARBPROC)wglGetProcAddress("wglCreateContextAttribsARB");
+        if(!wglCreateContextAttribsARB)
+        {
+                return false;
+        }
+
+        wglSwapIntervalEXT = (PFNWGLSWAPINTERVALEXTPROC)wglGetProcAddress("wglSwapIntervalEXT");
+        if(!wglSwapIntervalEXT)
+        {
+                return false;
+        }
+
+        glAttachShader = (PFNGLATTACHSHADERPROC)wglGetProcAddress("glAttachShader");
+        if(!glAttachShader)
+        {
+                return false;
+        }
+
+        glBindBuffer = (PFNGLBINDBUFFERPROC)wglGetProcAddress("glBindBuffer");
+        if(!glBindBuffer)
+        {
+                return false;
+        }
+
+        glBindVertexArray = (PFNGLBINDVERTEXARRAYPROC)wglGetProcAddress("glBindVertexArray");
+        if(!glBindVertexArray)
+        {
+                return false;
+        }
+
+        glBufferData = (PFNGLBUFFERDATAPROC)wglGetProcAddress("glBufferData");
+        if(!glBufferData)
+        {
+                return false;
+        }
+
+        glCompileShader = (PFNGLCOMPILESHADERPROC)wglGetProcAddress("glCompileShader");
+        if(!glCompileShader)
+        {
+                return false;
+        }
+
+        glCreateProgram = (PFNGLCREATEPROGRAMPROC)wglGetProcAddress("glCreateProgram");
+        if(!glCreateProgram)
+        {
+                return false;
+        }
+
+        glCreateShader = (PFNGLCREATESHADERPROC)wglGetProcAddress("glCreateShader");
+        if(!glCreateShader)
+        {
+                return false;
+        }
+
+        glDeleteBuffers = (PFNGLDELETEBUFFERSPROC)wglGetProcAddress("glDeleteBuffers");
+        if(!glDeleteBuffers)
+        {
+                return false;
+        }
+
+        glDeleteProgram = (PFNGLDELETEPROGRAMPROC)wglGetProcAddress("glDeleteProgram");
+        if(!glDeleteProgram)
+        {
+                return false;
+        }
+
+        glDeleteShader = (PFNGLDELETESHADERPROC)wglGetProcAddress("glDeleteShader");
+        if(!glDeleteShader)
+        {
+                return false;
+        }
+
+        glDeleteVertexArrays = (PFNGLDELETEVERTEXARRAYSPROC)wglGetProcAddress("glDeleteVertexArrays");
+        if(!glDeleteVertexArrays)
+        {
+                return false;
+        }
+
+        glDetachShader = (PFNGLDETACHSHADERPROC)wglGetProcAddress("glDetachShader");
+        if(!glDetachShader)
+        {
+                return false;
+        }
+
+        glEnableVertexAttribArray = (PFNGLENABLEVERTEXATTRIBARRAYPROC)wglGetProcAddress("glEnableVertexAttribArray");
+        if(!glEnableVertexAttribArray)
+        {
+                return false;
+        }
+
+        glGenBuffers = (PFNGLGENBUFFERSPROC)wglGetProcAddress("glGenBuffers");
+        if(!glGenBuffers)
+        {
+                return false;
+        }
+
+        glGenVertexArrays = (PFNGLGENVERTEXARRAYSPROC)wglGetProcAddress("glGenVertexArrays");
+        if(!glGenVertexArrays)
+        {
+                return false;
+        }
+
+        glGetAttribLocation = (PFNGLGETATTRIBLOCATIONPROC)wglGetProcAddress("glGetAttribLocation");
+        if(!glGetAttribLocation)
+        {
+                return false;
+        }
+
+        glGetProgramInfoLog = (PFNGLGETPROGRAMINFOLOGPROC)wglGetProcAddress("glGetProgramInfoLog");
+        if(!glGetProgramInfoLog)
+        {
+                return false;
+        }
+
+        glGetProgramiv = (PFNGLGETPROGRAMIVPROC)wglGetProcAddress("glGetProgramiv");
+        if(!glGetProgramiv)
+        {
+                return false;
+        }
+
+        glGetShaderInfoLog = (PFNGLGETSHADERINFOLOGPROC)wglGetProcAddress("glGetShaderInfoLog");
+        if(!glGetShaderInfoLog)
+        {
+                return false;
+        }
+
+        glGetShaderiv = (PFNGLGETSHADERIVPROC)wglGetProcAddress("glGetShaderiv");
+        if(!glGetShaderiv)
+        {
+                return false;
+        }
+
+        glLinkProgram = (PFNGLLINKPROGRAMPROC)wglGetProcAddress("glLinkProgram");
+        if(!glLinkProgram)
+        {
+                return false;
+        }
+
+        glShaderSource = (PFNGLSHADERSOURCEPROC)wglGetProcAddress("glShaderSource");
+        if(!glShaderSource)
+        {
+                return false;
+        }
+
+        glUseProgram = (PFNGLUSEPROGRAMPROC)wglGetProcAddress("glUseProgram");
+        if(!glUseProgram)
+        {
+                return false;
+        }
+
+        glVertexAttribPointer = (PFNGLVERTEXATTRIBPOINTERPROC)wglGetProcAddress("glVertexAttribPointer");
+        if(!glVertexAttribPointer)
+        {
+                return false;
+        }
+
+        glBindAttribLocation = (PFNGLBINDATTRIBLOCATIONPROC)wglGetProcAddress("glBindAttribLocation");
+        if(!glBindAttribLocation)
+        {
+                return false;
+        }
+
+        glGetUniformLocation = (PFNGLGETUNIFORMLOCATIONPROC)wglGetProcAddress("glGetUniformLocation");
+        if(!glGetUniformLocation)
+        {
+                return false;
+        }
+
+        glUniformMatrix4fv = (PFNGLUNIFORMMATRIX4FVPROC)wglGetProcAddress("glUniformMatrix4fv");
+        if(!glUniformMatrix4fv)
+        {
+                return false;
+        }
+
+        glActiveTexture = (PFNGLACTIVETEXTUREPROC)wglGetProcAddress("glActiveTexture");
+        if(!glActiveTexture)
+        {
+                return false;
+        }
+
+        glUniform1i = (PFNGLUNIFORM1IPROC)wglGetProcAddress("glUniform1i");
+        if(!glUniform1i)
+        {
+                return false;
+        }
+
+        glGenerateMipmap = (PFNGLGENERATEMIPMAPPROC)wglGetProcAddress("glGenerateMipmap");
+        if(!glGenerateMipmap)
+        {
+                return false;
+        }
+
+        glDisableVertexAttribArray = (PFNGLDISABLEVERTEXATTRIBARRAYPROC)wglGetProcAddress("glDisableVertexAttribArray");
+        if(!glDisableVertexAttribArray)
+        {
+                return false;
+        }
+
+        glUniform3fv = (PFNGLUNIFORM3FVPROC)wglGetProcAddress("glUniform3fv");
+        if(!glUniform3fv)
+        {
+                return false;
+        }
+
+        glUniform4fv = (PFNGLUNIFORM4FVPROC)wglGetProcAddress("glUniform4fv");
+        if(!glUniform4fv)
+        {
+                return false;
+        }
+
+        return true;
+}
+
+void FinalizeOpenGL(HWND hwnd)
+{
+        // Release the rendering context.
+        if(g_renderingContext)
+        {
+                wglMakeCurrent(NULL, NULL);
+                wglDeleteContext(g_renderingContext);
+                g_renderingContext = 0;
+        }
+
+        // Release the device context.
+        if(g_deviceContext)
+        {
+                ReleaseDC(hwnd, g_deviceContext);
+                g_deviceContext = 0;
+        }
+}
+
+void GetVideoCardInfo(char* cardName)
+{
+        strcpy_s(cardName, 128, g_videoCardDescription);
+        return;
+}
+
+bool InitializeExtensions(HWND hwnd)
+{
+        HDC deviceContext;
+        PIXELFORMATDESCRIPTOR pixelFormat;
+        int error;
+        HGLRC renderContext;
+        bool result;
+
+
+        // Get the device context for this window.
+        deviceContext = GetDC(hwnd);
+        if(!deviceContext)
+        {
+                return false;
+        }
+
+        // Set a temporary default pixel format.
+        error = SetPixelFormat(deviceContext, 1, &pixelFormat);
+        if(error != 1)
+        {
+                return false;
+        }
+
+        // Create a temporary rendering context.
+        renderContext = wglCreateContext(deviceContext);
+        if(!renderContext)
+        {
+                return false;
+        }
+
+        // Set the temporary rendering context as the current rendering context for this window.
+        error = wglMakeCurrent(deviceContext, renderContext);
+        if(error != 1)
+        {
+                return false;
+        }
+
+        // Initialize the OpenGL extensions needed for this application.  Note that a temporary rendering context was needed to do so.
+        result = LoadExtensionList();
+        if(!result)
+        {
+                return false;
+        }
+
+        // Release the temporary rendering context now that the extensions have been loaded.
+        wglMakeCurrent(NULL, NULL);
+        wglDeleteContext(renderContext);
+        renderContext = NULL;
+
+        // Release the device context for this window.
+        ReleaseDC(hwnd, deviceContext);
+        deviceContext = 0;
+
+        return true;
+}
+
+void OutputShaderErrorMessage(HWND hwnd, unsigned int shaderId, const char* shaderFilename)
+{
+        int logSize, i;
+        char* infoLog;
+        ofstream fout;
+        wchar_t newString[128];
+        unsigned int error;
+        size_t convertedChars;
+
+
+        // Get the size of the string containing the information log for the failed shader compilation message.
+        glGetShaderiv(shaderId, GL_INFO_LOG_LENGTH, &logSize);
+
+        // Increment the size by one to handle also the null terminator.
+        logSize++;
+
+        // Create a char buffer to hold the info log.
+        infoLog = new char[logSize];
+        if(!infoLog)
+        {
+                return;
+        }
+
+        // Now retrieve the info log.
+        glGetShaderInfoLog(shaderId, logSize, NULL, infoLog);
+
+        // Open a file to write the error message to.
+        fout.open("shader-error.txt");
+
+        // Write out the error message.
+        for(i=0; i<logSize; i++)
+        {
+                fout << infoLog[i];
+        }
+
+        // Close the file.
+        fout.close();
+
+        // Convert the shader filename to a wide character string.
+        error = mbstowcs_s(&convertedChars, newString, 128, shaderFilename, 128);
+        if(error != 0)
+        {
+                return;
+        }
+
+        // Pop a message up on the screen to notify the user to check the text file for compile errors.
+        MessageBoxW(hwnd, L"Error compiling shader.  Check shader-error.txt for message.", newString, MB_OK);
+
+        return;
+}
+
+void OutputLinkerErrorMessage(HWND hwnd, unsigned int programId)
+{
+        int logSize, i;
+        char* infoLog;
+        ofstream fout;
+
+
+        // Get the size of the string containing the information log for the failed shader compilation message.
+        glGetProgramiv(programId, GL_INFO_LOG_LENGTH, &logSize);
+
+        // Increment the size by one to handle also the null terminator.
+        logSize++;
+
+        // Create a char buffer to hold the info log.
+        infoLog = new char[logSize];
+        if(!infoLog)
+        {
+                return;
+        }
+
+        // Now retrieve the info log.
+        glGetProgramInfoLog(programId, logSize, NULL, infoLog);
+
+        // Open a file to write the error message to.
+        fout.open("linker-error.txt");
+
+        // Write out the error message.
+        for(i=0; i<logSize; i++)
+        {
+                fout << infoLog[i];
+        }
+
+        // Close the file.
+        fout.close();
+
+        // Pop a message up on the screen to notify the user to check the text file for linker errors.
+        MessageBox(hwnd, _T("Error compiling linker.  Check linker-error.txt for message."), _T("Linker Error"), MB_OK);
+}
+
+char* LoadShaderSourceFile(const char* filename)
+{
+        ifstream fin;
+        int fileSize;
+        char input;
+        char* buffer;
+
+
+        // Open the shader source file.
+        fin.open(filename);
+
+        // If it could not open the file then exit.
+        if(fin.fail())
+        {
+                return 0;
+        }
+
+        // Initialize the size of the file.
+        fileSize = 0;
+
+        // Read the first element of the file.
+        fin.get(input);
+
+        // Count the number of elements in the text file.
+        while(!fin.eof())
+        {
+                fileSize++;
+                fin.get(input);
+        }
+
+        // Close the file for now.
+        fin.close();
+
+        // Initialize the buffer to read the shader source file into.
+        buffer = new char[fileSize+1];
+        if(!buffer)
+        {
+                return 0;
+        }
+
+        // Open the shader source file again.
+        fin.open(filename);
+
+        // Read the shader text file into the buffer as a block.
+        fin.read(buffer, fileSize);
+
+        // Close the file.
+        fin.close();
+
+        // Null terminate the buffer.
+        buffer[fileSize] = '';
+
+        return buffer;
+}
+
+bool InitializeShader(HWND hwnd, const char* vsFilename, const char* fsFilename)
+{
+        const char* vertexShaderBuffer;
+        const char* fragmentShaderBuffer;
+        int status;
+
+        // Load the vertex shader source file into a text buffer.
+        vertexShaderBuffer = LoadShaderSourceFile(vsFilename);
+        if(!vertexShaderBuffer)
+        {
+                return false;
+        }
+
+        // Load the fragment shader source file into a text buffer.
+        fragmentShaderBuffer = LoadShaderSourceFile(fsFilename);
+        if(!fragmentShaderBuffer)
+        {
+                return false;
+        }
+
+        // Create a vertex and fragment shader object.
+        g_vertexShader = glCreateShader(GL_VERTEX_SHADER);
+        g_fragmentShader = glCreateShader(GL_FRAGMENT_SHADER);
+
+        // Copy the shader source code strings into the vertex and fragment shader objects.
+        glShaderSource(g_vertexShader, 1, &vertexShaderBuffer, NULL);
+        glShaderSource(g_fragmentShader, 1, &fragmentShaderBuffer, NULL);
+
+        // Release the vertex and fragment shader buffers.
+        delete [] vertexShaderBuffer;
+        vertexShaderBuffer = 0;
+
+        delete [] fragmentShaderBuffer;
+        fragmentShaderBuffer = 0;
+
+        // Compile the shaders.
+        glCompileShader(g_vertexShader);
+        glCompileShader(g_fragmentShader);
+
+        // Check to see if the vertex shader compiled successfully.
+        glGetShaderiv(g_vertexShader, GL_COMPILE_STATUS, &status);
+        if(status != 1)
+        {
+                // If it did not compile then write the syntax error message out to a text file for review.
+                OutputShaderErrorMessage(hwnd, g_vertexShader, vsFilename);
+                return false;
+        }
+
+        // Check to see if the fragment shader compiled successfully.
+        glGetShaderiv(g_fragmentShader, GL_COMPILE_STATUS, &status);
+        if(status != 1)
+        {
+                // If it did not compile then write the syntax error message out to a text file for review.
+                OutputShaderErrorMessage(hwnd, g_fragmentShader, fsFilename);
+                return false;
+        }
+
+        // Create a shader program object.
+        g_shaderProgram = glCreateProgram();
+
+        // Attach the vertex and fragment shader to the program object.
+        glAttachShader(g_shaderProgram, g_vertexShader);
+        glAttachShader(g_shaderProgram, g_fragmentShader);
+
+        // Bind the shader input variables.
+        glBindAttribLocation(g_shaderProgram, 0, "inputPosition");
+        glBindAttribLocation(g_shaderProgram, 1, "inputColor");
+
+        // Link the shader program.
+        glLinkProgram(g_shaderProgram);
+
+        // Check the status of the link.
+        glGetProgramiv(g_shaderProgram, GL_LINK_STATUS, &status);
+        if(status != 1)
+        {
+                // If it did not link then write the syntax error message out to a text file for review.
+                OutputLinkerErrorMessage(hwnd, g_shaderProgram);
+                return false;
+        }
+
+        return true;
+}
+
+void ShutdownShader()
+{
+        // Detach the vertex and fragment shaders from the program.
+        glDetachShader(g_shaderProgram, g_vertexShader);
+        glDetachShader(g_shaderProgram, g_fragmentShader);
+
+        // Delete the vertex and fragment shaders.
+        glDeleteShader(g_vertexShader);
+        glDeleteShader(g_fragmentShader);
+
+        // Delete the shader program.
+        glDeleteProgram(g_shaderProgram);
+}
+
+bool SetShaderParameters(float* worldMatrix, float* viewMatrix, float* projectionMatrix)
+{
+        unsigned int location;
+
+        // Set the world matrix in the vertex shader.
+        location = glGetUniformLocation(g_shaderProgram, "worldMatrix");
+        if(location == -1)
+        {
+                return false;
+        }
+        glUniformMatrix4fv(location, 1, false, worldMatrix);
+
+        // Set the view matrix in the vertex shader.
+        location = glGetUniformLocation(g_shaderProgram, "viewMatrix");
+        if(location == -1)
+        {
+                return false;
+        }
+        glUniformMatrix4fv(location, 1, false, viewMatrix);
+
+        // Set the projection matrix in the vertex shader.
+        location = glGetUniformLocation(g_shaderProgram, "projectionMatrix");
+        if(location == -1)
+        {
+                return false;
+        }
+        glUniformMatrix4fv(location, 1, false, projectionMatrix);
+
+        return true;
+}
+
+bool InitializeBuffers()
+{
+        VertexType vertices[] = {
+                       {{  1.0f,  1.0f,  1.0f }, { 1.0f, 0.0f, 0.0f }},
+                       {{  1.0f,  1.0f, -1.0f }, { 0.0f, 1.0f, 0.0f }},
+                       {{ -1.0f,  1.0f, -1.0f }, { 0.0f, 0.0f, 1.0f }},
+                       {{ -1.0f,  1.0f,  1.0f }, { 1.0f, 1.0f, 0.0f }},
+                       {{  1.0f, -1.0f,  1.0f }, { 1.0f, 0.0f, 1.0f }},
+                       {{  1.0f, -1.0f, -1.0f }, { 0.0f, 1.0f, 1.0f }},
+                       {{ -1.0f, -1.0f, -1.0f }, { 0.5f, 1.0f, 0.5f }},
+                       {{ -1.0f, -1.0f,  1.0f }, { 1.0f, 0.5f, 1.0f }},
+               };
+        uint16_t indices[] = { 1, 2, 3, 3, 2, 6, 6, 7, 3, 3, 0, 1, 0, 3, 7, 7, 6, 4, 4, 6, 5, 0, 7, 4, 1, 0, 4, 1, 4, 5, 2, 1, 5, 2, 5, 6 };
+
+        // Set the number of vertices in the vertex array.
+        g_vertexCount = sizeof(vertices) / sizeof(VertexType);
+
+        // Set the number of indices in the index array.
+        g_indexCount = sizeof(indices) / sizeof(uint16_t);
+
+        // Allocate an OpenGL vertex array object.
+        glGenVertexArrays(1, &g_vertexArrayId);
+
+        // Bind the vertex array object to store all the buffers and vertex attributes we create here.
+        glBindVertexArray(g_vertexArrayId);
+
+        // Generate an ID for the vertex buffer.
+        glGenBuffers(1, &g_vertexBufferId);
+
+        // Bind the vertex buffer and load the vertex (position and color) data into the vertex buffer.
+        glBindBuffer(GL_ARRAY_BUFFER, g_vertexBufferId);
+        glBufferData(GL_ARRAY_BUFFER, g_vertexCount * sizeof(VertexType), vertices, GL_STATIC_DRAW);
+
+        // Enable the two vertex array attributes.
+        glEnableVertexAttribArray(0);  // Vertex position.
+        glEnableVertexAttribArray(1);  // Vertex color.
+
+        // Specify the location and format of the position portion of the vertex buffer.
+        glBindBuffer(GL_ARRAY_BUFFER, g_vertexBufferId);
+        glVertexAttribPointer(0, 3, GL_FLOAT, false, sizeof(VertexType), 0);
+
+        // Specify the location and format of the color portion of the vertex buffer.
+        glBindBuffer(GL_ARRAY_BUFFER, g_vertexBufferId);
+        glVertexAttribPointer(1, 3, GL_FLOAT, false, sizeof(VertexType), (char*)NULL + (3 * sizeof(float)));
+
+        // Generate an ID for the index buffer.
+        glGenBuffers(1, &g_indexBufferId);
+
+        // Bind the index buffer and load the index data into it.
+        glBindBuffer(GL_ELEMENT_ARRAY_BUFFER, g_indexBufferId);
+        glBufferData(GL_ELEMENT_ARRAY_BUFFER, g_indexCount* sizeof(uint16_t), indices, GL_STATIC_DRAW);
+
+        return true;
+}
+
+void ShutdownBuffers()
+{
+        // Disable the two vertex array attributes.
+        glDisableVertexAttribArray(0);
+        glDisableVertexAttribArray(1);
+
+        // Release the vertex buffer.
+        glBindBuffer(GL_ARRAY_BUFFER, 0);
+        glDeleteBuffers(1, &g_vertexBufferId);
+
+        // Release the index buffer.
+        glBindBuffer(GL_ELEMENT_ARRAY_BUFFER, 0);
+        glDeleteBuffers(1, &g_indexBufferId);
+
+        // Release the vertex array object.
+        glBindVertexArray(0);
+        glDeleteVertexArrays(1, &g_vertexArrayId);
+
+        return;
+}
+
+void RenderBuffers()
+{
+        // Bind the vertex array object that stored all the information about the vertex and index buffers.
+        glBindVertexArray(g_vertexArrayId);
+
+        // Render the vertex buffer using the index buffer.
+        glDrawElements(GL_TRIANGLES, g_indexCount, GL_UNSIGNED_SHORT, 0);
+
+        return;
+}
+
+void CalculateCameraPosition()
+{
+    VectorType up, position, lookAt;
+    float yaw, pitch, roll;
+    float rotationMatrix[9];
+
+
+    // Setup the vector that points upwards.
+    up.x = 0.0f;
+    up.y = 1.0f;
+    up.z = 0.0f;
+
+    // Setup the position of the camera in the world.
+    position.x = g_positionX;
+    position.y = g_positionY;
+    position.z = g_positionZ;
+
+    // Setup where the camera is looking by default.
+    lookAt.x = 0.0f;
+    lookAt.y = 0.0f;
+    lookAt.z = 1.0f;
+
+    // Set the yaw (Y axis), pitch (X axis), and roll (Z axis) rotations in radians.
+    pitch = g_rotationX * 0.0174532925f;
+    yaw   = g_rotationY * 0.0174532925f;
+    roll  = g_rotationZ * 0.0174532925f;
+
+    // Create the rotation matrix from the yaw, pitch, and roll values.
+    MatrixRotationYawPitchRoll(rotationMatrix, yaw, pitch, roll);
+
+    // Transform the lookAt and up vector by the rotation matrix so the view is correctly rotated at the origin.
+    TransformCoord(lookAt, rotationMatrix);
+    TransformCoord(up, rotationMatrix);
+
+    // Translate the rotated camera position to the location of the viewer.
+    lookAt.x = position.x + lookAt.x;
+    lookAt.y = position.y + lookAt.y;
+    lookAt.z = position.z + lookAt.z;
+
+    // Finally create the view matrix from the three updated vectors.
+    BuildViewMatrix(position, lookAt, up, g_viewMatrix);
+}
+
+void Draw()
+{
+       static float rotateAngle = 0.0f;
+
+    // Set the color to clear the screen to.
+    glClearColor(0.2f, 0.3f, 0.4f, 1.0f);
+    // Clear the screen and depth buffer.
+    glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);
+
+       // Update world matrix to rotate the model
+       rotateAngle += PI / 120;
+       float rotationMatrixY[16];
+       float rotationMatrixZ[16];
+       MatrixRotationY(rotationMatrixY, rotateAngle);
+       MatrixRotationZ(rotationMatrixZ, rotateAngle);
+       MatrixMultiply(g_worldMatrix, rotationMatrixZ, rotationMatrixY);
+
+    // Generate the view matrix based on the camera's position.
+       CalculateCameraPosition();
+
+    // Set the color shader as the current shader program and set the matrices that it will use for rendering.
+       glUseProgram(g_shaderProgram);
+    SetShaderParameters(g_worldMatrix, g_viewMatrix, g_projectionMatrix);
+
+    // Render the model using the color shader.
+    RenderBuffers();
+
+    // Present the back buffer to the screen since rendering is complete.
+    SwapBuffers(g_deviceContext);
+}

 // the WindowProc function prototype
 LRESULT CALLBACK WindowProc(HWND hWnd,
@@ -25,32 +1049,75 @@ int WINAPI WinMain(HINSTANCE hInstance,

        // fill in the struct with the needed information
        wc.cbSize = sizeof(WNDCLASSEX);
-    wc.style = CS_HREDRAW | CS_VREDRAW;
+       wc.style = CS_HREDRAW | CS_VREDRAW | CS_OWNDC;
+    wc.lpfnWndProc = DefWindowProc;
+    wc.hInstance = hInstance;
+    wc.hCursor = LoadCursor(NULL, IDC_ARROW);
+    wc.hbrBackground = (HBRUSH)COLOR_WINDOW;
+    wc.lpszClassName = _T("Temporary");
+
+    // register the window class
+    RegisterClassEx(&wc);
+
+    // create the temporary window for OpenGL extension setup.
+    hWnd = CreateWindowEx(WS_EX_APPWINDOW,
+                          _T("Temporary"),    // name of the window class
+                          _T("Temporary"),   // title of the window
+                          WS_OVERLAPPEDWINDOW,    // window style
+                          0,    // x-position of the window
+                          0,    // y-position of the window
+                          640,    // width of the window
+                          480,    // height of the window
+                          NULL,    // we have no parent window, NULL
+                          NULL,    // we aren't using menus, NULL
+                          hInstance,    // application handle
+                          NULL);    // used with multiple windows, NULL
+
+                                                                       // Don't show the window.
+       ShowWindow(hWnd, SW_HIDE);
+
+    InitializeExtensions(hWnd);
+
+       DestroyWindow(hWnd);
+       hWnd = NULL;
+
+       // clear out the window class for use
+       ZeroMemory(&wc, sizeof(WNDCLASSEX));
+
+       // fill in the struct with the needed information
+       wc.cbSize = sizeof(WNDCLASSEX);
+       wc.style = CS_HREDRAW | CS_VREDRAW | CS_OWNDC;
        wc.lpfnWndProc = WindowProc;
        wc.hInstance = hInstance;
        wc.hCursor = LoadCursor(NULL, IDC_ARROW);
        wc.hbrBackground = (HBRUSH)COLOR_WINDOW;
-    wc.lpszClassName = _T("WindowClass1");
+       wc.lpszClassName = _T("Hello, Engine!");

        // register the window class
        RegisterClassEx(&wc);

        // create the window and use the result as the handle
-    hWnd = CreateWindowEx(0,
-                          _T("WindowClass1"),    // name of the window class
+       hWnd = CreateWindowEx(WS_EX_APPWINDOW,
+               _T("Hello, Engine!"),    // name of the window class
                _T("Hello, Engine!"),   // title of the window
                WS_OVERLAPPEDWINDOW,    // window style
                300,    // x-position of the window
                300,    // y-position of the window
-                          500,    // width of the window
-                          400,    // height of the window
+               960,    // width of the window
+               540,    // height of the window
                NULL,    // we have no parent window, NULL
                NULL,    // we aren't using menus, NULL
                hInstance,    // application handle
                NULL);    // used with multiple windows, NULL

+    InitializeOpenGL(hWnd, 960, 540, SCREEN_DEPTH, SCREEN_NEAR, true);
+
        // display the window on the screen
        ShowWindow(hWnd, nCmdShow);
+       SetForegroundWindow(hWnd);
+
+    InitializeShader(hWnd, VS_SHADER_SOURCE_FILE, PS_SHADER_SOURCE_FILE);
+    InitializeBuffers();

     // enter the main loop:

@@ -67,6 +1134,10 @@ int WINAPI WinMain(HINSTANCE hInstance,
         DispatchMessage(&msg);
     }

+    ShutdownBuffers();
+    ShutdownShader();
+    FinalizeOpenGL(hWnd);
+
     // return this part of the WM_QUIT message to Windows
     return msg.wParam;
 }
@@ -79,14 +1150,8 @@ LRESULT CALLBACK WindowProc(HWND hWnd, UINT message, WPARAM wParam, LPARAM lPara
     {
     case WM_PAINT:
         {
-               PAINTSTRUCT ps;
-               HDC hdc = BeginPaint(hWnd, &ps);
-               RECT rec = { 20, 20, 60, 80 };
-               HBRUSH brush = (HBRUSH) GetStockObject(BLACK_BRUSH);
-
-               FillRect(hdc, &rec, brush);
-
-               EndPaint(hWnd, &ps);
+          Draw();
+                 return 0;
         } break;
         // this message is read when the window is closed
     case WM_DESTROY:

#include <math.h>

#ifndef PI
#define PI 3.14159265358979323846f
#endif

#ifndef TWO_PI
#define TWO_PI 3.14159265358979323846f * 2.0f
#endif

typedef struct VectorType
{
	union {
		struct { float x, y, z; };
		struct { float r, g, b; };
	};
} VectorType;

void MatrixRotationYawPitchRoll(float* matrix, float yaw, float pitch, float roll)
{
	float cYaw, cPitch, cRoll, sYaw, sPitch, sRoll;


	// Get the cosine and sin of the yaw, pitch, and roll.
	cYaw = cosf(yaw);
	cPitch = cosf(pitch);
	cRoll = cosf(roll);

	sYaw = sinf(yaw);
	sPitch = sinf(pitch);
	sRoll = sinf(roll);

	// Calculate the yaw, pitch, roll rotation matrix.
	matrix[0] = (cRoll * cYaw) + (sRoll * sPitch * sYaw);
	matrix[1] = (sRoll * cPitch);
	matrix[2] = (cRoll * -sYaw) + (sRoll * sPitch * cYaw);

	matrix[3] = (-sRoll * cYaw) + (cRoll * sPitch * sYaw);
	matrix[4] = (cRoll * cPitch);
	matrix[5] = (sRoll * sYaw) + (cRoll * sPitch * cYaw);

	matrix[6] = (cPitch * sYaw);
	matrix[7] = -sPitch;
	matrix[8] = (cPitch * cYaw);

	return;
}

void TransformCoord(VectorType& vector, float* matrix)
{
	float x, y, z;


	// Transform the vector by the 3x3 matrix.
	x = (vector.x * matrix[0]) + (vector.y * matrix[3]) + (vector.z * matrix[6]);
	y = (vector.x * matrix[1]) + (vector.y * matrix[4]) + (vector.z * matrix[7]);
	z = (vector.x * matrix[2]) + (vector.y * matrix[5]) + (vector.z * matrix[8]);

	// Store the result in the reference.
	vector.x = x;
	vector.y = y;
	vector.z = z;

	return;
}

void BuildViewMatrix(VectorType position, VectorType lookAt, VectorType up, float* result)
{
	VectorType zAxis, xAxis, yAxis;
	float length, result1, result2, result3;


	// zAxis = normal(lookAt - position)
	zAxis.x = lookAt.x - position.x;
	zAxis.y = lookAt.y - position.y;
	zAxis.z = lookAt.z - position.z;
	length = sqrt((zAxis.x * zAxis.x) + (zAxis.y * zAxis.y) + (zAxis.z * zAxis.z));
	zAxis.x = zAxis.x / length;
	zAxis.y = zAxis.y / length;
	zAxis.z = zAxis.z / length;

	// xAxis = normal(cross(up, zAxis))
	xAxis.x = (up.y * zAxis.z) - (up.z * zAxis.y);
	xAxis.y = (up.z * zAxis.x) - (up.x * zAxis.z);
	xAxis.z = (up.x * zAxis.y) - (up.y * zAxis.x);
	length = sqrt((xAxis.x * xAxis.x) + (xAxis.y * xAxis.y) + (xAxis.z * xAxis.z));
	xAxis.x = xAxis.x / length;
	xAxis.y = xAxis.y / length;
	xAxis.z = xAxis.z / length;

	// yAxis = cross(zAxis, xAxis)
	yAxis.x = (zAxis.y * xAxis.z) - (zAxis.z * xAxis.y);
	yAxis.y = (zAxis.z * xAxis.x) - (zAxis.x * xAxis.z);
	yAxis.z = (zAxis.x * xAxis.y) - (zAxis.y * xAxis.x);

	// -dot(xAxis, position)
	result1 = ((xAxis.x * position.x) + (xAxis.y * position.y) + (xAxis.z * position.z)) * -1.0f;

	// -dot(yaxis, eye)
	result2 = ((yAxis.x * position.x) + (yAxis.y * position.y) + (yAxis.z * position.z)) * -1.0f;

	// -dot(zaxis, eye)
	result3 = ((zAxis.x * position.x) + (zAxis.y * position.y) + (zAxis.z * position.z)) * -1.0f;

	// Set the computed values in the view matrix.
	result[0]  = xAxis.x;
	result[1]  = yAxis.x;
	result[2]  = zAxis.x;
	result[3]  = 0.0f;

	result[4]  = xAxis.y;
	result[5]  = yAxis.y;
	result[6]  = zAxis.y;
	result[7]  = 0.0f;

	result[8]  = xAxis.z;
	result[9]  = yAxis.z;
	result[10] = zAxis.z;
	result[11] = 0.0f;

	result[12] = result1;
	result[13] = result2;
	result[14] = result3;
	result[15] = 1.0f;
}

void BuildIdentityMatrix(float* matrix)
{
	matrix[0] = 1.0f;
	matrix[1] = 0.0f;
	matrix[2] = 0.0f;
	matrix[3] = 0.0f;

	matrix[4] = 0.0f;
	matrix[5] = 1.0f;
	matrix[6] = 0.0f;
	matrix[7] = 0.0f;

	matrix[8] = 0.0f;
	matrix[9] = 0.0f;
	matrix[10] = 1.0f;
	matrix[11] = 0.0f;

	matrix[12] = 0.0f;
	matrix[13] = 0.0f;
	matrix[14] = 0.0f;
	matrix[15] = 1.0f;

	return;
}


void BuildPerspectiveFovLHMatrix(float* matrix, float fieldOfView, float screenAspect, float screenNear, float screenDepth)
{
	matrix[0] = 1.0f / (screenAspect * tan(fieldOfView * 0.5f));
	matrix[1] = 0.0f;
	matrix[2] = 0.0f;
	matrix[3] = 0.0f;

	matrix[4] = 0.0f;
	matrix[5] = 1.0f / tan(fieldOfView * 0.5f);
	matrix[6] = 0.0f;
	matrix[7] = 0.0f;

	matrix[8] = 0.0f;
	matrix[9] = 0.0f;
	matrix[10] = screenDepth / (screenDepth - screenNear);
	matrix[11] = 1.0f;

	matrix[12] = 0.0f;
	matrix[13] = 0.0f;
	matrix[14] = (-screenNear * screenDepth) / (screenDepth - screenNear);
	matrix[15] = 0.0f;

	return;
}


void MatrixRotationY(float* matrix, float angle)
{
	matrix[0] = cosf(angle);
	matrix[1] = 0.0f;
	matrix[2] = -sinf(angle);
	matrix[3] = 0.0f;

	matrix[4] = 0.0f;
	matrix[5] = 1.0f;
	matrix[6] = 0.0f;
	matrix[7] = 0.0f;

	matrix[8] = sinf(angle);
	matrix[9] = 0.0f;
	matrix[10] = cosf(angle);
	matrix[11] = 0.0f;

	matrix[12] = 0.0f;
	matrix[13] = 0.0f;
	matrix[14] = 0.0f;
	matrix[15] = 1.0f;

	return;
}


void MatrixTranslation(float* matrix, float x, float y, float z)
{
	matrix[0] = 1.0f;
	matrix[1] = 0.0f;
	matrix[2] = 0.0f;
	matrix[3] = 0.0f;

	matrix[4] = 0.0f;
	matrix[5] = 1.0f;
	matrix[6] = 0.0f;
	matrix[7] = 0.0f;

	matrix[8] = 0.0f;
	matrix[9] = 0.0f;
	matrix[10] = 1.0f;
	matrix[11] = 0.0f;

	matrix[12] = x;
	matrix[13] = y;
	matrix[14] = z;
	matrix[15] = 1.0f;

	return;
}


void MatrixRotationZ(float* matrix, float angle)
{
	matrix[0] = cosf(angle);
	matrix[1] = -sinf(angle);
	matrix[2] = 0.0f;
	matrix[3] = 0.0f;

	matrix[4] = sinf(angle);
	matrix[5] = cosf(angle);
	matrix[6] = 0.0f;
	matrix[7] = 0.0f;

	matrix[8] = 0.0f;
	matrix[9] = 0.0f;
	matrix[10] = 1.0f;
	matrix[11] = 0.0f;

	matrix[12] = 0.0f;
	matrix[13] = 0.0f;
	matrix[14] = 0.0f;
	matrix[15] = 1.0f;

	return;
}


void MatrixMultiply(float* result, float* matrix1, float* matrix2)
{
	result[0] = (matrix1[0] * matrix2[0]) + (matrix1[1] * matrix2[4]) + (matrix1[2] * matrix2[8]) + (matrix1[3] * matrix2[12]);
	result[1] = (matrix1[0] * matrix2[1]) + (matrix1[1] * matrix2[5]) + (matrix1[2] * matrix2[9]) + (matrix1[3] * matrix2[13]);
	result[2] = (matrix1[0] * matrix2[2]) + (matrix1[1] * matrix2[6]) + (matrix1[2] * matrix2[10]) + (matrix1[3] * matrix2[14]);
	result[3] = (matrix1[0] * matrix2[3]) + (matrix1[1] * matrix2[7]) + (matrix1[2] * matrix2[11]) + (matrix1[3] * matrix2[15]);

	result[4] = (matrix1[4] * matrix2[0]) + (matrix1[5] * matrix2[4]) + (matrix1[6] * matrix2[8]) + (matrix1[7] * matrix2[12]);
	result[5] = (matrix1[4] * matrix2[1]) + (matrix1[5] * matrix2[5]) + (matrix1[6] * matrix2[9]) + (matrix1[7] * matrix2[13]);
	result[6] = (matrix1[4] * matrix2[2]) + (matrix1[5] * matrix2[6]) + (matrix1[6] * matrix2[10]) + (matrix1[7] * matrix2[14]);
	result[7] = (matrix1[4] * matrix2[3]) + (matrix1[5] * matrix2[7]) + (matrix1[6] * matrix2[11]) + (matrix1[7] * matrix2[15]);

	result[8] = (matrix1[8] * matrix2[0]) + (matrix1[9] * matrix2[4]) + (matrix1[10] * matrix2[8]) + (matrix1[11] * matrix2[12]);
	result[9] = (matrix1[8] * matrix2[1]) + (matrix1[9] * matrix2[5]) + (matrix1[10] * matrix2[9]) + (matrix1[11] * matrix2[13]);
	result[10] = (matrix1[8] * matrix2[2]) + (matrix1[9] * matrix2[6]) + (matrix1[10] * matrix2[10]) + (matrix1[11] * matrix2[14]);
	result[11] = (matrix1[8] * matrix2[3]) + (matrix1[9] * matrix2[7]) + (matrix1[10] * matrix2[11]) + (matrix1[11] * matrix2[15]);

	result[12] = (matrix1[12] * matrix2[0]) + (matrix1[13] * matrix2[4]) + (matrix1[14] * matrix2[8]) + (matrix1[15] * matrix2[12]);
	result[13] = (matrix1[12] * matrix2[1]) + (matrix1[13] * matrix2[5]) + (matrix1[14] * matrix2[9]) + (matrix1[15] * matrix2[13]);
	result[14] = (matrix1[12] * matrix2[2]) + (matrix1[13] * matrix2[6]) + (matrix1[14] * matrix2[10]) + (matrix1[15] * matrix2[14]);
	result[15] = (matrix1[12] * matrix2[3]) + (matrix1[13] * matrix2[7]) + (matrix1[14] * matrix2[11]) + (matrix1[15] * matrix2[15]);

	return;
}

D:wenliSourceReposGameEngineFromScratchPlatformWindows>cl /EHsc /Z7 opengl32.lib user32.lib gdi32.lib helloengine_opengl.cpp

D:wenliSourceReposGameEngineFromScratchPlatformWindows>clang-cl /EHsc -o helloengine_opengl helloengine_opengl.cpp user32.lib gdi32.lib opengl32.lib

D:wenliSourceReposGameEngineFromScratchPlatformWindows>clang -o helloengine_opengl helloengine_opengl.cpp -luser32 -lgdi32 -lopengl32
helloengine_opengl-99755a.o : warning LNK4217: 本地定义的符号 ___std_terminate 在函数 "int `public: virtual __thiscall std::basic_filebuf<char,struct std::char_traits<char> >::~basic_filebuf<char,struct std::char_traits<char> >(void)'::`1'::dtor$8" (?dtor$8@?0???1?$basic_filebuf@DU?$char_traits@D@std@@@std@@UAE@XZ@4HA) 中导入
helloengine_opengl-99755a.o : warning LNK4217: 本地定义的符号 __CxxThrowException@8 在函数 "class std::codecvt<char,char,struct _Mbstatet> const & __cdecl std::use_facet<class std::codecvt<char,char,struct _Mbstatet> >(class std::locale const &)" (??$use_facet@V?$codecvt@DDU_Mbstatet@@@std@@@std@@YAABV?$codecvt@DDU_Mbstatet@@@0@ABVlocale@0@@Z) 中导入

////////////////////////////////////////////////////////////////////////////////
// Filename: color.vs
////////////////////////////////////////////////////////////////////////////////

#version 400

/////////////////////
// INPUT VARIABLES //
/////////////////////
in vec3 inputPosition;
in vec3 inputColor;

//////////////////////
// OUTPUT VARIABLES //
//////////////////////
out vec3 color;

///////////////////////
// UNIFORM VARIABLES //
///////////////////////
uniform mat4 worldMatrix;
uniform mat4 viewMatrix;
uniform mat4 projectionMatrix;

////////////////////////////////////////////////////////////////////////////////
// Vertex Shader
////////////////////////////////////////////////////////////////////////////////
void main(void)
{
	// Calculate the position of the vertex against the world, view, and projection matrices.
	gl_Position = worldMatrix * vec4(inputPosition, 1.0f);
	gl_Position = viewMatrix * gl_Position;
	gl_Position = projectionMatrix * gl_Position;

	// Store the input color for the pixel shader to use.
	color = inputColor;
}

////////////////////////////////////////////////////////////////////////////////
// Filename: color.ps
////////////////////////////////////////////////////////////////////////////////
#version 400


/////////////////////
// INPUT VARIABLES //
/////////////////////
in vec3 color;


//////////////////////
// OUTPUT VARIABLES //
//////////////////////
out vec4 outputColor;


////////////////////////////////////////////////////////////////////////////////
// Pixel Shader
////////////////////////////////////////////////////////////////////////////////
void main(void)
{
	outputColor = vec4(color, 1.0f);
}

 #include <stdlib.h>
 #include <string.h>

+#include <X11/Xlib.h>
+#include <X11/Xlib-xcb.h>
 #include <xcb/xcb.h>

+#include <GL/gl.h>
+#include <GL/glx.h>
+#include <GL/glu.h>
+
+#define GLX_CONTEXT_MAJOR_VERSION_ARB       0x2091
+#define GLX_CONTEXT_MINOR_VERSION_ARB       0x2092
+typedef GLXContext (*glXCreateContextAttribsARBProc)(Display*, GLXFBConfig, GLXContext, Bool, const int*);
+
+// Helper to check for extension string presence.  Adapted from:
+//   http://www.opengl.org/resources/features/OGLextensions/
+static bool isExtensionSupported(const char *extList, const char *extension)
+{
+  const char *start;
+  const char *where, *terminator;
+
+  /* Extension names should not have spaces. */
+  where = strchr(extension, ' ');
+  if (where || *extension == '')
+    return false;
+
+  /* It takes a bit of care to be fool-proof about parsing the
+     OpenGL extensions string. Don't be fooled by sub-strings,
+     etc. */
+  for (start=extList;;) {
+    where = strstr(start, extension);
+
+    if (!where)
+      break;
+
+    terminator = where + strlen(extension);
+
+    if ( where == start || *(where - 1) == ' ' )
+      if ( *terminator == ' ' || *terminator == '' )
+        return true;
+
+    start = terminator;
+  }
+
+  return false;
+}
+
+static bool ctxErrorOccurred = false;
+static int ctxErrorHandler(Display *dpy, XErrorEvent *ev)
+{
+    ctxErrorOccurred = true;
+    return 0;
+}
+
+void DrawAQuad() {
+    glClearColor(1.0, 1.0, 1.0, 1.0);
+    glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);
+
+    glMatrixMode(GL_PROJECTION);
+    glLoadIdentity();
+    glOrtho(-1., 1., -1., 1., 1., 20.);
+
+    glMatrixMode(GL_MODELVIEW);
+    glLoadIdentity();
+    gluLookAt(0., 0., 10., 0., 0., 0., 0., 1., 0.);
+
+    glBegin(GL_QUADS);
+    glColor3f(1., 0., 0.);
+    glVertex3f(-.75, -.75, 0.);
+    glColor3f(0., 1., 0.);
+    glVertex3f( .75, -.75, 0.);
+    glColor3f(0., 0., 1.);
+    glVertex3f( .75, .75, 0.);
+    glColor3f(1., 1., 0.);
+    glVertex3f(-.75, .75, 0.);
+    glEnd();
+}
+
 int main(void) {
     xcb_connection_t    *pConn;
     xcb_screen_t        *pScreen;
@@ -11,41 +85,145 @@ int main(void) {
     xcb_gcontext_t      foreground;
     xcb_gcontext_t      background;
     xcb_generic_event_t *pEvent;
+    xcb_colormap_t colormap;
     uint32_t        mask = 0;
-       uint32_t                values[2];
+    uint32_t        values[3];
     uint8_t         isQuit = 0;

-       char title[] = "Hello, Engine!";
+    char title[] = "Hello, Engine![OpenGL]";
     char title_icon[] = "Hello, Engine! (iconified)";

+    Display *display;
+    int default_screen;
+    GLXContext context;
+    GLXFBConfig *fb_configs;
+    GLXFBConfig fb_config;
+    int num_fb_configs = 0;
+    XVisualInfo *vi;
+    GLXDrawable drawable;
+    GLXWindow glxwindow;
+    glXCreateContextAttribsARBProc glXCreateContextAttribsARB;
+    const char *glxExts;
+
+    // Get a matching FB config
+    static int visual_attribs[] =
+    {
+      GLX_X_RENDERABLE    , True,
+      GLX_DRAWABLE_TYPE   , GLX_WINDOW_BIT,
+      GLX_RENDER_TYPE     , GLX_RGBA_BIT,
+      GLX_X_VISUAL_TYPE   , GLX_TRUE_COLOR,
+      GLX_RED_SIZE        , 8,
+      GLX_GREEN_SIZE      , 8,
+      GLX_BLUE_SIZE       , 8,
+      GLX_ALPHA_SIZE      , 8,
+      GLX_DEPTH_SIZE      , 24,
+      GLX_STENCIL_SIZE    , 8,
+      GLX_DOUBLEBUFFER    , True,
+      //GLX_SAMPLE_BUFFERS  , 1,
+      //GLX_SAMPLES         , 4,
+      None
+    };
+
+    int glx_major, glx_minor;
+
+    /* Open Xlib Display */
+    display = XOpenDisplay(NULL);
+    if(!display)
+    {
+        fprintf(stderr, "Can't open displayn");
+        return -1;
+    }
+
+    // FBConfigs were added in GLX version 1.3.
+    if (!glXQueryVersion(display, &glx_major, &glx_minor) ||
+       ((glx_major == 1) && (glx_minor < 3)) || (glx_major < 1))
+    {
+        fprintf(stderr, "Invalid GLX versionn");
+        return -1;
+    }
+
+    default_screen = DefaultScreen(display);
+
+    /* Query framebuffer configurations */
+    fb_configs = glXChooseFBConfig(display, default_screen, visual_attribs, &num_fb_configs);
+    if(!fb_configs || num_fb_configs == 0)
+    {
+        fprintf(stderr, "glXGetFBConfigs failedn");
+        return -1;
+    }
+
+    /* Pick the FB config/visual with the most samples per pixel */
+    {
+        int best_fbc = -1, worst_fbc = -1, best_num_samp = -1, worst_num_samp = 999;
+
+        for (int i=0; i<num_fb_configs; ++i)
+        {
+            XVisualInfo *vi = glXGetVisualFromFBConfig(display, fb_configs[i]);
+            if (vi)
+            {
+                int samp_buf, samples;
+                glXGetFBConfigAttrib(display, fb_configs[i], GLX_SAMPLE_BUFFERS, &samp_buf);
+                glXGetFBConfigAttrib(display, fb_configs[i], GLX_SAMPLES, &samples);
+
+                printf( "  Matching fbconfig %d, visual ID 0x%lx: SAMPLE_BUFFERS = %d,"
+                        " SAMPLES = %dn",
+                        i, vi -> visualid, samp_buf, samples);
+
+                if (best_fbc < 0 || (samp_buf && samples > best_num_samp))
+                    best_fbc = i, best_num_samp = samples;
+                if (worst_fbc < 0 || !samp_buf || samples < worst_num_samp)
+                    worst_fbc = i, worst_num_samp = samples;
+            }
+            XFree( vi );
+        }
+
+        fb_config = fb_configs[best_fbc];
+    }
+
+    /* Get a visual */
+    vi = glXGetVisualFromFBConfig(display, fb_config);
+    printf("Chosen visual ID = 0x%lxn", vi->visualid);
+
     /* establish connection to X server */
-       pConn = xcb_connect(0, 0);
+    pConn = XGetXCBConnection(display);
+    if(!pConn)
+    {
+        XCloseDisplay(display);
+        fprintf(stderr, "Can't get xcb connection from displayn");
+        return -1;
+    }

-       /* get the first screen */
-       pScreen = xcb_setup_roots_iterator(xcb_get_setup(pConn)).data;
+    /* Acquire event queue ownership */
+    XSetEventQueueOwner(display, XCBOwnsEventQueue);
+
+    /* Find XCB screen */
+    xcb_screen_iterator_t screen_iter =
+        xcb_setup_roots_iterator(xcb_get_setup(pConn));
+    for(int screen_num = vi->screen;
+        screen_iter.rem && screen_num > 0;
+        --screen_num, xcb_screen_next(&screen_iter));
+    pScreen = screen_iter.data;

     /* get the root window */
     window = pScreen->root;

-       /* create black (foreground) graphic context */
-       foreground = xcb_generate_id(pConn);
-       mask = XCB_GC_FOREGROUND | XCB_GC_GRAPHICS_EXPOSURES;
-       values[0] = pScreen->black_pixel;
-       values[1] = 0;
-       xcb_create_gc(pConn, foreground, window, mask, values);
+    /* Create XID's for colormap */
+    colormap = xcb_generate_id(pConn);

-       /* create which (background) graphic context */
-       background = xcb_generate_id(pConn);
-       mask = XCB_GC_BACKGROUND | XCB_GC_GRAPHICS_EXPOSURES;
-       values[0] = pScreen->white_pixel;
-       values[1] = 0;
-       xcb_create_gc(pConn, background, window, mask, values);
+    xcb_create_colormap(
+        pConn,
+        XCB_COLORMAP_ALLOC_NONE,
+        colormap,
+        window,
+        vi->visualid
+        );

     /* create window */
     window = xcb_generate_id(pConn);
-       mask = XCB_CW_BACK_PIXEL | XCB_CW_EVENT_MASK;
-       values[0] = pScreen->white_pixel;
-       values[1] = XCB_EVENT_MASK_EXPOSURE | XCB_EVENT_MASK_KEY_PRESS;
+    mask = XCB_CW_EVENT_MASK  | XCB_CW_COLORMAP;
+    values[0] = XCB_EVENT_MASK_EXPOSURE | XCB_EVENT_MASK_KEY_PRESS;
+    values[1] = colormap;
+    values[2] = 0;
     xcb_create_window (pConn,                   /* connection */
                        XCB_COPY_FROM_PARENT,    /* depth */
                        window,                  /* window ID */
@@ -54,9 +232,11 @@ int main(void) {
                        640, 480,                /* width, height */
                        10,                      /* boarder width */
                        XCB_WINDOW_CLASS_INPUT_OUTPUT, /* class */
-                                          pScreen->root_visual,        /* visual */
+                       vi->visualid,            /* visual */
                        mask, values);           /* masks */

+    XFree(vi);
+
     /* set the title of the window */
     xcb_change_property(pConn, XCB_PROP_MODE_REPLACE, window,
                 XCB_ATOM_WM_NAME, XCB_ATOM_STRING, 8,
@@ -72,13 +252,120 @@ int main(void) {

     xcb_flush(pConn);


+    /* Get the default screen's GLX extension list */
+    glxExts = glXQueryExtensionsString(display, default_screen);
+
+    /* NOTE: It is not necessary to create or make current to a context before
+       calling glXGetProcAddressARB */
+    glXCreateContextAttribsARB = (glXCreateContextAttribsARBProc)
+           glXGetProcAddressARB( (const GLubyte *) "glXCreateContextAttribsARB" );
+
+    /* Create OpenGL context */
+    ctxErrorOccurred = false;
+    int (*oldHandler)(Display*, XErrorEvent*) =
+        XSetErrorHandler(&ctxErrorHandler);
+
+    if (!isExtensionSupported(glxExts, "GLX_ARB_create_context") ||
+       !glXCreateContextAttribsARB )
+    {
+        printf( "glXCreateContextAttribsARB() not found"
+            " ... using old-style GLX contextn" );
+        context = glXCreateNewContext(display, fb_config, GLX_RGBA_TYPE, 0, True);
+        if(!context)
+        {
+            fprintf(stderr, "glXCreateNewContext failedn");
+            return -1;
+        }
+    }
+    else
+    {
+        int context_attribs[] =
+          {
+            GLX_CONTEXT_MAJOR_VERSION_ARB, 3,
+            GLX_CONTEXT_MINOR_VERSION_ARB, 0,
+            None
+          };
+
+        printf( "Creating contextn" );
+        context = glXCreateContextAttribsARB(display, fb_config, 0,
+                                          True, context_attribs );
+
+        XSync(display, False);
+        if (!ctxErrorOccurred && context)
+          printf( "Created GL 3.0 contextn" );
+        else
+        {
+          /* GLX_CONTEXT_MAJOR_VERSION_ARB = 1 */
+          context_attribs[1] = 1;
+          /* GLX_CONTEXT_MINOR_VERSION_ARB = 0 */
+          context_attribs[3] = 0;
+
+          ctxErrorOccurred = false;
+
+          printf( "Failed to create GL 3.0 context"
+                  " ... using old-style GLX contextn" );
+          context = glXCreateContextAttribsARB(display, fb_config, 0,
+                                            True, context_attribs );
+        }
+    }
+
+    XSync(display, False);
+
+    XSetErrorHandler(oldHandler);
+
+    if (ctxErrorOccurred || !context)
+    {
+        printf( "Failed to create an OpenGL contextn" );
+        return -1;
+    }
+
+    /* Verifying that context is a direct context */
+    if (!glXIsDirect (display, context))
+    {
+        printf( "Indirect GLX rendering context obtainedn" );
+    }
+    else
+    {
+        printf( "Direct GLX rendering context obtainedn" );
+    }
+
+    /* Create GLX Window */
+    glxwindow =
+            glXCreateWindow(
+                display,
+                fb_config,
+                window,
+                0
+                );
+
+    if(!window)
+    {
+        xcb_destroy_window(pConn, window);
+        glXDestroyContext(display, context);
+
+        fprintf(stderr, "glXDestroyContext failedn");
+        return -1;
+    }
+
+    drawable = glxwindow;
+
+    /* make OpenGL context current */
+    if(!glXMakeContextCurrent(display, drawable, drawable, context))
+    {
+        xcb_destroy_window(pConn, window);
+        glXDestroyContext(display, context);
+
+        fprintf(stderr, "glXMakeContextCurrent failedn");
+        return -1;
+    }
+
+
-       while((pEvent = xcb_wait_for_event(pConn)) && !isQuit) {
+    while(!isQuit && (pEvent = xcb_wait_for_event(pConn))) {
         switch(pEvent->response_type & ~0x80) {
         case XCB_EXPOSE:
             {
-                       xcb_rectangle_t rect = { 20, 20, 60, 80 };
-                       xcb_poly_fill_rectangle(pConn, window, foreground, 1, &rect);
-                       xcb_flush(pConn);
+                DrawAQuad();
+                glXSwapBuffers(display, drawable);
             }
             break;
         case XCB_KEY_PRESS:
@@ -88,6 +375,8 @@ int main(void) {
         free(pEvent);
     }

+
+    /* Cleanup */
     xcb_disconnect(pConn);

     return 0;

    // Get a matching FB config
    static int visual_attribs[] =
    {
      GLX_X_RENDERABLE    , True,
      GLX_DRAWABLE_TYPE   , GLX_WINDOW_BIT,
      GLX_RENDER_TYPE     , GLX_RGBA_BIT,
      GLX_X_VISUAL_TYPE   , GLX_TRUE_COLOR,
      GLX_RED_SIZE        , 8,
      GLX_GREEN_SIZE      , 8,
      GLX_BLUE_SIZE       , 8,
      GLX_ALPHA_SIZE      , 8,
      GLX_DEPTH_SIZE      , 24,
      GLX_STENCIL_SIZE    , 8,
      GLX_DOUBLEBUFFER    , True,
      //GLX_SAMPLE_BUFFERS  , 1,
      //GLX_SAMPLES         , 4,
      None
    };

    /* Query framebuffer configurations */
    fb_configs = glXChooseFBConfig(display, default_screen, visual_attribs, &num_fb_configs);
    if(!fb_configs || num_fb_configs == 0)
    {
        fprintf(stderr, "glXGetFBConfigs failedn");
        return -1;
    }

    /* Pick the FB config/visual with the most samples per pixel */
    {
        int best_fbc = -1, worst_fbc = -1, best_num_samp = -1, worst_num_samp = 999;

        for (int i=0; i<num_fb_configs; ++i)
        {
            XVisualInfo *vi = glXGetVisualFromFBConfig(display, fb_configs[i]);
            if (vi)
            {
                int samp_buf, samples;
                glXGetFBConfigAttrib(display, fb_configs[i], GLX_SAMPLE_BUFFERS, &samp_buf);
                glXGetFBConfigAttrib(display, fb_configs[i], GLX_SAMPLES, &samples);

                printf( "  Matching fbconfig %d, visual ID 0x%lx: SAMPLE_BUFFERS = %d,"
                        " SAMPLES = %dn",
                        i, vi -> visualid, samp_buf, samples);

                if (best_fbc < 0 || (samp_buf && samples > best_num_samp))
                    best_fbc = i, best_num_samp = samples;
                if (worst_fbc < 0 || !samp_buf || samples < worst_num_samp)
                    worst_fbc = i, worst_num_samp = samples;
            }
            XFree( vi );
        }

        fb_config = fb_configs[best_fbc];
    }

    /* establish connection to X server */
    pConn = XGetXCBConnection(display);
    if(!pConn)
    {
        XCloseDisplay(display);
        fprintf(stderr, "Can't get xcb connection from displayn");
        return -1;
    }

    /* Acquire event queue ownership */
    XSetEventQueueOwner(display, XCBOwnsEventQueue);

    /* Find XCB screen */
    xcb_screen_iterator_t screen_iter =
        xcb_setup_roots_iterator(xcb_get_setup(pConn));
    for(int screen_num = vi->screen;
        screen_iter.rem && screen_num > 0;
        --screen_num, xcb_screen_next(&screen_iter));
    pScreen = screen_iter.data;

    /* Get the default screen's GLX extension list */
    glxExts = glXQueryExtensionsString(display, default_screen);

    /* NOTE: It is not necessary to create or make current to a context before
       calling glXGetProcAddressARB */
    glXCreateContextAttribsARB = (glXCreateContextAttribsARBProc)
           glXGetProcAddressARB( (const GLubyte *) "glXCreateContextAttribsARB" );

    /* Create OpenGL context */
    ctxErrorOccurred = false;
    int (*oldHandler)(Display*, XErrorEvent*) =
        XSetErrorHandler(&ctxErrorHandler);

    if (!isExtensionSupported(glxExts, "GLX_ARB_create_context") ||
       !glXCreateContextAttribsARB )
    {
        printf( "glXCreateContextAttribsARB() not found"
            " ... using old-style GLX contextn" );
        context = glXCreateNewContext(display, fb_config, GLX_RGBA_TYPE, 0, True);
        if(!context)
        {
            fprintf(stderr, "glXCreateNewContext failedn");
            return -1;
        }
    }
    else
    {
        int context_attribs[] =
          {
            GLX_CONTEXT_MAJOR_VERSION_ARB, 3,
            GLX_CONTEXT_MINOR_VERSION_ARB, 0,
            None
          };

        printf( "Creating contextn" );
        context = glXCreateContextAttribsARB(display, fb_config, 0,
                                          True, context_attribs );

        XSync(display, False);
        if (!ctxErrorOccurred && context)
          printf( "Created GL 3.0 contextn" );
        else
        {
          /* GLX_CONTEXT_MAJOR_VERSION_ARB = 1 */
          context_attribs[1] = 1;
          /* GLX_CONTEXT_MINOR_VERSION_ARB = 0 */
          context_attribs[3] = 0;

          ctxErrorOccurred = false;

          printf( "Failed to create GL 3.0 context"
                  " ... using old-style GLX contextn" );
          context = glXCreateContextAttribsARB(display, fb_config, 0,
                                            True, context_attribs );
        }
    }

    XSync(display, False);

    XSetErrorHandler(oldHandler);

    if (ctxErrorOccurred || !context)
    {
        printf( "Failed to create an OpenGL contextn" );
        return -1;
    }

    /* Create GLX Window */
    glxwindow =
            glXCreateWindow(
                display,
                fb_config,
                window,
                0
                );

    if(!window)
    {
        xcb_destroy_window(pConn, window);
        glXDestroyContext(display, context);

        fprintf(stderr, "glXDestroyContext failedn");
        return -1;
    }

    drawable = glxwindow;

    /* make OpenGL context current */
    if(!glXMakeContextCurrent(display, drawable, drawable, context))
    {
        xcb_destroy_window(pConn, window);
        glXDestroyContext(display, context);

        fprintf(stderr, "glXMakeContextCurrent failedn");
        return -1;
    }

    while(!isQuit && (pEvent = xcb_wait_for_event(pConn))) {
        switch(pEvent->response_type & ~0x80) {
        case XCB_EXPOSE:
            {
                DrawAQuad();
                glXSwapBuffers(display, drawable);
            }
            break;
        case XCB_KEY_PRESS:
            isQuit = 1;
            break;
        }
        free(pEvent);
    }

[tim@localhost Linux]$ clang -lxcb -lX11 -lX11-xcb -lGL -lGLU -o helloengine_opengl helloengine_opengl.cpp

void DrawAQuad() {
    glClearColor(1.0, 1.0, 1.0, 1.0);
    glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);

    glMatrixMode(GL_PROJECTION);
    glLoadIdentity();
    glOrtho(-1., 1., -1., 1., 1., 20.);

    glMatrixMode(GL_MODELVIEW);
    glLoadIdentity();
    gluLookAt(0., 0., 10., 0., 0., 0., 0., 1., 0.);

    glBegin(GL_QUADS);
    glColor3f(1., 0., 0.);
    glVertex3f(-.75, -.75, 0.);
    glColor3f(0., 1., 0.);
    glVertex3f( .75, -.75, 0.);
    glColor3f(0., 0., 1.);
    glVertex3f( .75, .75, 0.);
    glColor3f(1., 1., 0.);
    glVertex3f(-.75, .75, 0.);
    glEnd();
}

@@ -3,6 +3,63 @@
 #include <windowsx.h>
 #include <tchar.h>

+#include <d2d1.h>
+
+ID2D1Factory           *pFactory = nullptr;
+ID2D1HwndRenderTarget  *pRenderTarget = nullptr;
+ID2D1SolidColorBrush   *pLightSlateGrayBrush = nullptr;
+ID2D1SolidColorBrush   *pCornflowerBlueBrush = nullptr;
+
+template<class T>
+inline void SafeRelease(T **ppInterfaceToRelease)
+{
+    if (*ppInterfaceToRelease != nullptr)
+    {
+        (*ppInterfaceToRelease)->Release();
+
+        (*ppInterfaceToRelease) = nullptr;
+    }
+}
+
+HRESULT CreateGraphicsResources(HWND hWnd)
+{
+    HRESULT hr = S_OK;
+    if (pRenderTarget == nullptr)
+    {
+        RECT rc;
+        GetClientRect(hWnd, &rc);
+
+        D2D1_SIZE_U size = D2D1::SizeU(rc.right - rc.left,
+                        rc.bottom - rc.top);
+
+        hr = pFactory->CreateHwndRenderTarget(
+            D2D1::RenderTargetProperties(),
+            D2D1::HwndRenderTargetProperties(hWnd, size),
+            &pRenderTarget);
+
+        if (SUCCEEDED(hr))
+        {
+            hr = pRenderTarget->CreateSolidColorBrush(D2D1::ColorF(D2D1::ColorF::LightSlateGray), &pLightSlateGrayBrush);
+
+        }
+
+        if (SUCCEEDED(hr))
+        {
+            hr = pRenderTarget->CreateSolidColorBrush(D2D1::ColorF(D2D1::ColorF::CornflowerBlue), &pCornflowerBlueBrush);
+
+        }
+    }
+    return hr;
+}
+
+void DiscardGraphicsResources()
+{
+    SafeRelease(&pRenderTarget);
+    SafeRelease(&pLightSlateGrayBrush);
+    SafeRelease(&pCornflowerBlueBrush);
+}
+
+
 // the WindowProc function prototype
 LRESULT CALLBACK WindowProc(HWND hWnd,
                          UINT message,
@@ -20,6 +77,9 @@ int WINAPI WinMain(HINSTANCE hInstance,
     // this struct holds information for the window class
     WNDCLASSEX wc;

+    // initialize COM
+    if (FAILED(CoInitializeEx(nullptr, COINIT_APARTMENTTHREADED | COINIT_DISABLE_OLE1DDE))) return -1;
+
     // clear out the window class for use
     ZeroMemory(&wc, sizeof(WNDCLASSEX));

@@ -28,7 +88,7 @@ int WINAPI WinMain(HINSTANCE hInstance,
     wc.style = CS_HREDRAW | CS_VREDRAW;
     wc.lpfnWndProc = WindowProc;
     wc.hInstance = hInstance;
-    wc.hCursor = LoadCursor(NULL, IDC_ARROW);
+    wc.hCursor = LoadCursor(nullptr, IDC_ARROW);
     wc.hbrBackground = (HBRUSH)COLOR_WINDOW;
     wc.lpszClassName = _T("WindowClass1");

@@ -38,12 +98,12 @@ int WINAPI WinMain(HINSTANCE hInstance,
     // create the window and use the result as the handle
     hWnd = CreateWindowEx(0,
                           _T("WindowClass1"),    // name of the window class
-                          _T("Hello, Engine!"),   // title of the window
+                          _T("Hello, Engine![Direct 2D]"),   // title of the window
                           WS_OVERLAPPEDWINDOW,    // window style
-                          300,    // x-position of the window
-                          300,    // y-position of the window
-                          500,    // width of the window
-                          400,    // height of the window
+                          100,    // x-position of the window
+                          100,    // y-position of the window
+                          960,    // width of the window
+                          540,    // height of the window
                           NULL,    // we have no parent window, NULL
                           NULL,    // we aren't using menus, NULL
                           hInstance,    // application handle
@@ -58,7 +118,7 @@ int WINAPI WinMain(HINSTANCE hInstance,
     MSG msg;

     // wait for the next message in the queue, store the result in 'msg'
-    while(GetMessage(&msg, NULL, 0, 0))
+    while(GetMessage(&msg, nullptr, 0, 0))
     {
         // translate keystroke messages into the right format
         TranslateMessage(&msg);
@@ -67,6 +127,9 @@ int WINAPI WinMain(HINSTANCE hInstance,
         DispatchMessage(&msg);
     }

+    // uninitialize COM
+    CoUninitialize();
+
     // return this part of the WM_QUIT message to Windows
     return msg.wParam;
 }
@@ -74,30 +137,126 @@ int WINAPI WinMain(HINSTANCE hInstance,
 // this is the main message handler for the program
 LRESULT CALLBACK WindowProc(HWND hWnd, UINT message, WPARAM wParam, LPARAM lParam)
 {
+    LRESULT result = 0;
+    bool wasHandled = false;
+
     // sort through and find what code to run for the message given
     switch(message)
     {
+       case WM_CREATE:
+               if (FAILED(D2D1CreateFactory(
+                                       D2D1_FACTORY_TYPE_SINGLE_THREADED, &pFactory)))
+               {
+                       result = -1; // Fail CreateWindowEx.

+                       return result;
+               }
+               wasHandled = true;
+        result = 0;
+        break;
+
        case WM_PAINT:
            {
-               PAINTSTRUCT ps;
-               HDC hdc = BeginPaint(hWnd, &ps);
-               RECT rec = { 20, 20, 60, 80 };
-               HBRUSH brush = (HBRUSH) GetStockObject(BLACK_BRUSH);
-
-               FillRect(hdc, &rec, brush);
-
-               EndPaint(hWnd, &ps);
-           } break;
-        // this message is read when the window is closed
-        case WM_DESTROY:
-            {
-                // close the application entirely
-                PostQuitMessage(0);
-                return 0;
-            } break;
+                       HRESULT hr = CreateGraphicsResources(hWnd);
+                       if (SUCCEEDED(hr))
+                       {
+                               PAINTSTRUCT ps;
+                               BeginPaint(hWnd, &ps);
+
+                               // start build GPU draw command
+                               pRenderTarget->BeginDraw();
+
+                               // clear the background with white color
+                               pRenderTarget->Clear(D2D1::ColorF(D2D1::ColorF::White));
+
+                // retrieve the size of drawing area
+                D2D1_SIZE_F rtSize = pRenderTarget->GetSize();
+
+                // draw a grid background.
+                int width = static_cast<int>(rtSize.width);
+                int height = static_cast<int>(rtSize.height);
+
+                for (int x = 0; x < width; x += 10)
+                {
+                    pRenderTarget->DrawLine(
+                        D2D1::Point2F(static_cast<FLOAT>(x), 0.0f),
+                        D2D1::Point2F(static_cast<FLOAT>(x), rtSize.height),
+                        pLightSlateGrayBrush,
+                        0.5f
+                        );
+                }
+
+                for (int y = 0; y < height; y += 10)
+                {
+                    pRenderTarget->DrawLine(
+                        D2D1::Point2F(0.0f, static_cast<FLOAT>(y)),
+                        D2D1::Point2F(rtSize.width, static_cast<FLOAT>(y)),
+                        pLightSlateGrayBrush,
+                        0.5f
+                        );
+                }
+
+                // draw two rectangles
+                D2D1_RECT_F rectangle1 = D2D1::RectF(
+                     rtSize.width/2 - 50.0f,
+                     rtSize.height/2 - 50.0f,
+                     rtSize.width/2 + 50.0f,
+                     rtSize.height/2 + 50.0f
+                     );
+
+                 D2D1_RECT_F rectangle2 = D2D1::RectF(
+                     rtSize.width/2 - 100.0f,
+                     rtSize.height/2 - 100.0f,
+                     rtSize.width/2 + 100.0f,
+                     rtSize.height/2 + 100.0f
+                     );
+
+                // draw a filled rectangle
+                pRenderTarget->FillRectangle(&rectangle1, pLightSlateGrayBrush);
+
+                // draw a outline only rectangle
+                pRenderTarget->DrawRectangle(&rectangle2, pCornflowerBlueBrush);
+
+                               // end GPU draw command building
+                               hr = pRenderTarget->EndDraw();
+                               if (FAILED(hr) || hr == D2DERR_RECREATE_TARGET)
+                               {
+                                       DiscardGraphicsResources();
+                               }
+
+                               EndPaint(hWnd, &ps);
+                       }
+           }
+               wasHandled = true;
+        break;
+
+       case WM_SIZE:
+               if (pRenderTarget != nullptr)
+               {
+                       RECT rc;
+                       GetClientRect(hWnd, &rc);
+
+                       D2D1_SIZE_U size = D2D1::SizeU(rc.right - rc.left, rc.bottom - rc.top);
+
+                       pRenderTarget->Resize(size);
+               }
+               wasHandled = true;
+        break;
+
+       case WM_DESTROY:
+               DiscardGraphicsResources();
+               if (pFactory) {pFactory->Release(); pFactory=nullptr; }
+               PostQuitMessage(0);
+        result = 0;
+               wasHandled = true;
+        break;
+
+    case WM_DISPLAYCHANGE:
+        InvalidateRect(hWnd, nullptr, false);
+        wasHandled = true;
+        break;
     }

     // Handle any messages the switch statement didn't
-    return DefWindowProc (hWnd, message, wParam, lParam);
+    if (!wasHandled) { result = DefWindowProc (hWnd, message, wParam, lParam); }
+    return result;
 }

ID2D1Factory           *pFactory = nullptr;
ID2D1HwndRenderTarget  *pRenderTarget = nullptr;
ID2D1SolidColorBrush   *pLightSlateGrayBrush = nullptr;
ID2D1SolidColorBrush   *pCornflowerBlueBrush = nullptr;

+
+template<class T>
+inline void SafeRelease(T **ppInterfaceToRelease)
+{
+    if (*ppInterfaceToRelease != nullptr)
+    {
+        (*ppInterfaceToRelease)->Release();
+
+        (*ppInterfaceToRelease) = nullptr;
+    }
+}
+

+HRESULT CreateGraphicsResources(HWND hWnd)
+{
+    HRESULT hr = S_OK;
+    if (pRenderTarget == nullptr)
+    {
+        RECT rc;
+        GetClientRect(hWnd, &rc);
+
+        D2D1_SIZE_U size = D2D1::SizeU(rc.right - rc.left,
+                        rc.bottom - rc.top);
+
+        hr = pFactory->CreateHwndRenderTarget(
+            D2D1::RenderTargetProperties(),
+            D2D1::HwndRenderTargetProperties(hWnd, size),
+            &pRenderTarget);
+
+        if (SUCCEEDED(hr))
+        {
+            hr = pRenderTarget->CreateSolidColorBrush(D2D1::ColorF(D2D1::ColorF::LightSlateGray), &pLightSlateGrayBrush);
+
+        }
+
+        if (SUCCEEDED(hr))
+        {
+            hr = pRenderTarget->CreateSolidColorBrush(D2D1::ColorF(D2D1::ColorF::CornflowerBlue), &pCornflowerBlueBrush);
+
+        }
+    }
+    return hr;
+}

+void DiscardGraphicsResources()
+{
+    SafeRelease(&pRenderTarget);
+    SafeRelease(&pLightSlateGrayBrush);
+    SafeRelease(&pCornflowerBlueBrush);
+}
+

+    // initialize COM
+    if (FAILED(CoInitializeEx(nullptr, COINIT_APARTMENTTHREADED | COINIT_DISABLE_OLE1DDE))) return -1;
+

+    // uninitialize COM
+    CoUninitialize();
+

+       case WM_CREATE:
+               if (FAILED(D2D1CreateFactory(
+                                       D2D1_FACTORY_TYPE_SINGLE_THREADED, &pFactory)))
+               {
+                       result = -1; // Fail CreateWindowEx.

+                       return result;
+               }
+               wasHandled = true;
+        result = 0;
+        break;
+

+                       HRESULT hr = CreateGraphicsResources(hWnd);
+                       if (SUCCEEDED(hr))
+                       {
+                               PAINTSTRUCT ps;
+                               BeginPaint(hWnd, &ps);
+
+                               // start build GPU draw command
+                               pRenderTarget->BeginDraw();
+
+                               // clear the background with white color
+                               pRenderTarget->Clear(D2D1::ColorF(D2D1::ColorF::White));
+
+                // retrieve the size of drawing area
+                D2D1_SIZE_F rtSize = pRenderTarget->GetSize();
+
+                // draw a grid background.
+                int width = static_cast<int>(rtSize.width);
+                int height = static_cast<int>(rtSize.height);
+
+                for (int x = 0; x < width; x += 10)
+                {
+                    pRenderTarget->DrawLine(
+                        D2D1::Point2F(static_cast<FLOAT>(x), 0.0f),
+                        D2D1::Point2F(static_cast<FLOAT>(x), rtSize.height),
+                        pLightSlateGrayBrush,
+                        0.5f
+                        );
+                }
+
+                for (int y = 0; y < height; y += 10)
+                {
+                    pRenderTarget->DrawLine(
+                        D2D1::Point2F(0.0f, static_cast<FLOAT>(y)),
+                        D2D1::Point2F(rtSize.width, static_cast<FLOAT>(y)),
+                        pLightSlateGrayBrush,
+                        0.5f
+                        );
+                }
+
+                // draw two rectangles
+                D2D1_RECT_F rectangle1 = D2D1::RectF(
+                     rtSize.width/2 - 50.0f,
+                     rtSize.height/2 - 50.0f,
+                     rtSize.width/2 + 50.0f,
+                     rtSize.height/2 + 50.0f
+                     );
+
+                 D2D1_RECT_F rectangle2 = D2D1::RectF(
+                     rtSize.width/2 - 100.0f,
+                     rtSize.height/2 - 100.0f,
+                     rtSize.width/2 + 100.0f,
+                     rtSize.height/2 + 100.0f
+                     );
+
+                // draw a filled rectangle
+                pRenderTarget->FillRectangle(&rectangle1, pLightSlateGrayBrush);
+
+                // draw a outline only rectangle
+                pRenderTarget->DrawRectangle(&rectangle2, pCornflowerBlueBrush);
+
+                               // end GPU draw command building
+                               hr = pRenderTarget->EndDraw();
+                               if (FAILED(hr) || hr == D2DERR_RECREATE_TARGET)
+                               {
+                                       DiscardGraphicsResources();
+                               }
+
+                               EndPaint(hWnd, &ps);
+                       }
+           }
+               wasHandled = true;
+        break;

+       case WM_SIZE:
+               if (pRenderTarget != nullptr)
+               {
+                       RECT rc;
+                       GetClientRect(hWnd, &rc);
+
+                       D2D1_SIZE_U size = D2D1::SizeU(rc.right - rc.left, rc.bottom - rc.top);
+
+                       pRenderTarget->Resize(size);
+               }
+               wasHandled = true;
+        break;

+    case WM_DISPLAYCHANGE:
+        InvalidateRect(hWnd, nullptr, false);
+        wasHandled = true;
+        break;

+    if (!wasHandled) { result = DefWindowProc (hWnd, message, wParam, lParam); }
+    return result;

D:wenliSourceReposGameEngineFromScratchPlatformWindows>clang -l user32.lib -l ole32.lib -l d2d1.lib -o helloengine_d2d.exe helloengine_d2d.cpp

D:wenliSourceReposGameEngineFromScratchPlatformWindows>clang-cl -c -Z7 -o helloengine_d2d.obj helloengine_d2d.cpp

D:wenliSourceReposGameEngineFromScratchPlatformWindows>link -debug user32.lib ole32.lib d2d1.lib helloengine_d2d.obj

D:wenliSourceReposGameEngineFromScratchPlatformWindows>devenv /debug helloengine_d2d.exe

D:wenliSourceReposGameEngineFromScratchPlatformWindows>cl -l user32.lib helloengine_win.c
用于 x86 的 Microsoft (R) C/C++ 优化编译器 19.11.25506 版
版权所有(C) Microsoft Corporation。保留所有权利。

cl: 命令行 warning D9002 :忽略未知选项“-l”
helloengine_win.c
Microsoft (R) Incremental Linker Version 14.11.25506.0
Copyright (C) Microsoft Corporation.  All rights reserved.

/out:helloengine_win.exe
user32.lib
helloengine_win.obj

D:wenliSourceReposGameEngineFromScratchPlatformWindows>git diff helloengine_win.c
diff --git a/Platform/Windows/helloengine_win.c b/Platform/Windows/helloengine_win.c
index 041462a..b996344 100644
--- a/Platform/Windows/helloengine_win.c
+++ b/Platform/Windows/helloengine_win.c
@@ -77,6 +77,17 @@ LRESULT CALLBACK WindowProc(HWND hWnd, UINT message, WPARAM wParam, LPARAM lPara
     // sort through and find what code to run for the message given
     switch(message)
     {
+       case WM_PAINT:
+           {
+               PAINTSTRUCT ps;
+               HDC hdc = BeginPaint(hWnd, &ps);
+               RECT rec = { 20, 20, 60, 80 };
+               HBRUSH brush = (HBRUSH) GetStockObject(BLACK_BRUSH);
+
+               FillRect(hdc, &rec, brush);
+
+               EndPaint(hWnd, &ps);
+           } break;
         // this message is read when the window is closed
         case WM_DESTROY:
             {

D:wenliSourceReposGameEngineFromScratchPlatformWindows>cl user32.lib gdi32.lib helloengine_win.c

D:wenliSourceReposGameEngineFromScratchPlatformWindows>git add helloengine_win.c

D:wenliSourceReposGameEngineFromScratchPlatformWindows>git commit -m "in the middle of article_9"
[master 7f05a0e] in the middle of article_9
 1 file changed, 11 insertions(+)

diff --git a/Platform/Linux/helloengine_xcb.c b/Platform/Linux/helloengine_xcb.c
index 62cb467..7e44b48 100644
--- a/Platform/Linux/helloengine_xcb.c
+++ b/Platform/Linux/helloengine_xcb.c
@@ -75,6 +75,11 @@ int main(void) {
        while((pEvent = xcb_wait_for_event(pConn)) && !isQuit) {
                switch(pEvent->response_type & ~0x80) {
                case XCB_EXPOSE:
+                   {
+                       xcb_rectangle_t rect = { 20, 20, 60, 80 };
+                       xcb_poly_fill_rectangle(pConn, window, foreground, 1, &r
+                       xcb_flush(pConn);
+                   }
                        break;
                case XCB_KEY_PRESS:
                        isQuit = 1;
@@ -83,6 +88,8 @@ int main(void) {
                free(pEvent);
        }

+       xcb_disconnect(pConn);
+
        return 0;

tim@iZuf6iup3mphicesefdwajZ:~/src/GameEngineFromScratch/Platform/Linux$ clang -lxcb -o helloengine_xcb helloengine_xcb.c

tim@iZuf6iup3mphicesefdwajZ:~/src/GameEngineFromScratch/Platform/Linux$ git status
# On branch article_8
# Your branch is ahead of 'origin/article_8' by 1 commit.
#   (use "git push" to publish your local commits)
#
# Changes not staged for commit:
#   (use "git add <file>..." to update what will be committed)
#   (use "git checkout -- <file>..." to discard changes in working directory)
#
#       modified:   helloengine_xcb.c
#
# Untracked files:
#   (use "git add <file>..." to include in what will be committed)
#
#       helloengine_xcb
no changes added to commit (use "git add" and/or "git commit -a")
tim@iZuf6iup3mphicesefdwajZ:~/src/GameEngineFromScratch/Platform/Linux$ git add helloengine_xcb.c
tim@iZuf6iup3mphicesefdwajZ:~/src/GameEngineFromScratch/Platform/Linux$ git commit -m "end of article_9"
[article_8 c502b89] end of article_9
 1 file changed, 7 insertions(+)

#include <stdio.h>
#include <stdlib.h>
#include <string.h>

#include <xcb/xcb.h>

int main(void) {
        xcb_connection_t        *pConn;
        xcb_screen_t            *pScreen;
        xcb_window_t            window;
        xcb_gcontext_t          foreground;
        xcb_gcontext_t          background;
        xcb_generic_event_t     *pEvent;
        uint32_t                mask = 0;
        uint32_t                values[2];
        uint8_t                 isQuit = 0;

        char title[] = "Hello, Engine!";
        char title_icon[] = "Hello, Engine! (iconified)";

        /* establish connection to X server */
        pConn = xcb_connect(0, 0);

        /* get the first screen */
        pScreen = xcb_setup_roots_iterator(xcb_get_setup(pConn)).data;

        /* get the root window */
        window = pScreen->root;

        /* create black (foreground) graphic context */
        foreground = xcb_generate_id(pConn);
        mask = XCB_GC_FOREGROUND | XCB_GC_GRAPHICS_EXPOSURES;
        values[0] = pScreen->black_pixel;
        values[1] = 0;
        xcb_create_gc(pConn, foreground, window, mask, values);

        /* create white (background) graphic context */
        background = xcb_generate_id(pConn);
        mask = XCB_GC_BACKGROUND | XCB_GC_GRAPHICS_EXPOSURES;
        values[0] = pScreen->white_pixel;
        values[1] = 0;
        xcb_create_gc(pConn, background, window, mask, values);

        /* create window */
        window = xcb_generate_id(pConn);
        mask = XCB_CW_BACK_PIXEL | XCB_CW_EVENT_MASK;
        values[0] = pScreen->white_pixel;
        values[1] = XCB_EVENT_MASK_EXPOSURE | XCB_EVENT_MASK_KEY_PRESS;
        xcb_create_window (pConn,                                       /* connection */
                                           XCB_COPY_FROM_PARENT,        /* depth */
                                           window,                                      /* window ID */
                                           pScreen->root,                       /* parent window */
                                           20, 20,                                      /* x, y */
                                           640, 480,                            /* width, height */
                                           10,                                          /* boarder width */
                                           XCB_WINDOW_CLASS_INPUT_OUTPUT, /* class */
                                           pScreen->root_visual,        /* visual */
                                           mask, values);                       /* masks */

        /* set the title of the window */
        xcb_change_property(pConn, XCB_PROP_MODE_REPLACE, window,
                            XCB_ATOM_WM_NAME, XCB_ATOM_STRING, 8,
                            strlen(title), title);

        /* set the title of the window icon */
        xcb_change_property(pConn, XCB_PROP_MODE_REPLACE, window,
                            XCB_ATOM_WM_ICON_NAME, XCB_ATOM_STRING, 8,
                            strlen(title_icon), title_icon);

        /* map the window on the screen */
        xcb_map_window(pConn, window);

        xcb_flush(pConn);

        while((pEvent = xcb_wait_for_event(pConn)) && !isQuit) {
                switch(pEvent->response_type & ~0x80) {
                case XCB_EXPOSE:
                        break;
                case XCB_KEY_PRESS:
                        isQuit = 1;
                        break;
                }
                free(pEvent);
        }

        return 0;
}

tim@iZuf6iup3mphicesefdwajZ:~/src/GameEngineFromScratch/Platform/Linux$ clang -lxcb -o helloengine_xcb helloengine_xcb.c

[tim@iZ625ivhudwZ GameEngineFromScratch]$ git checkout -b article_7
Switched to a new branch 'article_7'

[tim@iZ625ivhudwZ GameEngineFromScratch]$ mkdir Platform
[tim@iZ625ivhudwZ GameEngineFromScratch]$ cd Platform

[tim@iZ625ivhudwZ Platform]$ mkdir Windows
[tim@iZ625ivhudwZ Platform]$ cd Windows

// include the basic windows header file
#include <windows.h>
#include <windowsx.h>
#include <tchar.h>

// the WindowProc function prototype
LRESULT CALLBACK WindowProc(HWND hWnd,
                         UINT message,
                         WPARAM wParam,
                         LPARAM lParam);

// the entry point for any Windows program
int WINAPI WinMain(HINSTANCE hInstance,
                   HINSTANCE hPrevInstance,
                   LPTSTR lpCmdLine,
                   int nCmdShow)
{
    // the handle for the window, filled by a function
    HWND hWnd;
    // this struct holds information for the window class
    WNDCLASSEX wc;

    // clear out the window class for use
    ZeroMemory(&wc, sizeof(WNDCLASSEX));

    // fill in the struct with the needed information
    wc.cbSize = sizeof(WNDCLASSEX);
    wc.style = CS_HREDRAW | CS_VREDRAW;
    wc.lpfnWndProc = WindowProc;
    wc.hInstance = hInstance;
    wc.hCursor = LoadCursor(NULL, IDC_ARROW);
    wc.hbrBackground = (HBRUSH)COLOR_WINDOW;
    wc.lpszClassName = _T("WindowClass1");

    // register the window class
    RegisterClassEx(&wc);

    // create the window and use the result as the handle
    hWnd = CreateWindowEx(0,
                          _T("WindowClass1"),    // name of the window class
                          _T("Hello, Engine!"),   // title of the window
                          WS_OVERLAPPEDWINDOW,    // window style
                          300,    // x-position of the window
                          300,    // y-position of the window
                          500,    // width of the window
                          400,    // height of the window
                          NULL,    // we have no parent window, NULL
                          NULL,    // we aren't using menus, NULL
                          hInstance,    // application handle
                          NULL);    // used with multiple windows, NULL

    // display the window on the screen
    ShowWindow(hWnd, nCmdShow);

    // enter the main loop:

    // this struct holds Windows event messages
    MSG msg;

    // wait for the next message in the queue, store the result in 'msg'
    while(GetMessage(&msg, NULL, 0, 0))
    {
        // translate keystroke messages into the right format
        TranslateMessage(&msg);

        // send the message to the WindowProc function
        DispatchMessage(&msg);
    }

    // return this part of the WM_QUIT message to Windows
    return msg.wParam;
}

// this is the main message handler for the program
LRESULT CALLBACK WindowProc(HWND hWnd, UINT message, WPARAM wParam, LPARAM lParam)
{
    // sort through and find what code to run for the message given
    switch(message)
    {
        // this message is read when the window is closed
        case WM_DESTROY:
            {
                // close the application entirely
                PostQuitMessage(0);
                return 0;
            } break;
    }

    // Handle any messages the switch statement didn't
    return DefWindowProc (hWnd, message, wParam, lParam);
}
